Page 64
FIGURE 82
FIELD SUPPLIED AIR FILTER
MOUNTED IN RETURN AIR DUCT
SECURE FILTER SWITCH
TO BLOWER HOUSING OR INSIDE MULLION
ATTACH HOSE TO HIGH SIDE OF SWITCH
BLOWER HOUSING
HORIZONTAL SUPPLY AND RETURN AIR COVERS
ROUTE HOSE THROUGH DUCT TO OPPOSITE
SIDE OF FILTER
LEAVE LOW SIDE OF SWITCH OPEN TO
ATMOSPHERE OF BLOWER COMPARTMENT
GCS16 UNIT
SUPPLY AIR RETURN AIR
TYPICAL FILTER SWITCH INSTALLATION
