Lennox GCS16-653-75

Page 12
FIGURE 4
GCS16H CONTROL BOX
IGNITION CONTROL
CONTACTOR
TRANSFORMER
COMPRESSOR
RUN CAPACITOR
COMBUSTION AIR
BLOWER RELAY
BLOWER RELAY
FIGURE 5
BLOWER/LIMIT
CONTROL S47
COMPRESSOR
CONTACTOR
INDOOR BLOWER RELAY K20
(HEATING SPEED)
460V & 575V UNITS ONLY
TERMINAL STRIP TB1
(GCS16 ONLY)
TRANSFORMER T1
TRANSFORMER T3
GCS16R-411 / GCS16-410 CONTROL BOX
INDOOR BLOWER RELAY K3
(COOLING SPEED)
COMBUSTION AIR BLOWER
RELAY K13
FUSE F1
460V & 575V UNITS ONLY
