Lennox GCS16-653-75

Page 24
PLUMBING COMPONENTS
THERMAL EXPANSION VALVE SYSTEMS
GCS16-511/513
GCS16R-511
GCS16-651/653
GCS16R-651
FIGURE 23
HIGH PRESSURE SWITCH
(GCS16 only)
CONDENSER COIL
EVAPORATOR COIL
LIQUID LINE
DISCHARGE LINE
STRAINER
EXPANSION VALVE
CONDENSER COIL
EVAPORATOR
COIL
THERMOMETER
WELL and LIQUID
GAUGE PORT
COMPRESSOR TERMINAL BOX
COMPRESSOR TERMINAL BOX
EXPANSION VALVE
LIQUID LINE
SUCTION LINE
SUCTION LINE
DISCHARGE LINE
HIGH PRESSURE SWITCH
(GCS16 only)
LOSS OF CHARGE SWITCH
(GCS16 only)
HIGH PRESSURE AND LOSS OF CHARGE SWITCHES USED ON GCS16 UNITS ONLY.
STRAINER
SUCTION LINE
GAUGE PORT
THERMOMETER
WELL and LIQUID
GAUGE PORT
SUCTION LINE
GAUGE PORT
LOSS OF CHARGE SWITCH
(GCS16 only)
