ELECTRICAL DATA
Model No. HS29-461 HS29-463 HS29-511 HS29-513
Line voltage data 60 hz
208/230v
1ph
208/230v
3ph
460v
3ph
208/230v
1ph
208/230v
3ph
460v
3ph
575v
3ph
Rated load amps 17.5 12.8 6.4 23.4 14.0 7.1 5.8
Compressor Power factor .98 .93 .93 .98 .88 .88 .88
Locked rotor amps 92.0 87.0 44.0 110.0 91.0 46.0 37.0
Condenser Coil
Full load amps 1.1 1.1 0.55 1.9 1.9 0.90 0.90
Fan Motor
Locked rotor amps 1.9 1.9 1.0 4.1 4.1 2.1 2.1
Rec. maximum fuse or circuit breaker size (amps) 40 25 15 50 30 15 10
*Minimum circuit ampacity 23.0 17.1 8.6 31.2 19.4 9.8 8.2
*Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
NOTE Extremes of operating range are plus 10% and minus 5% of line voltage.
ELECTRICAL DATA
Model No. HS29-651 HS29-653 HS29-681 HS29-683
Line voltage data 60 hz
208/230v
1ph
208/230v
3ph
460v
3ph
575v
3ph
208/230v
1ph
208/230v
3ph
460v
3ph
Rated load amps 26.9 17.3 9.0 7.1 27.1 18.6 7.9
Compressor Power factor .98 .86 .86 .86 .97 .86 .86
Locked rotor amps 123.0 128.0 64.0 51.0 175.0 128.0 63.0
Condenser Coil
Full load amps 1.9 1.9 0.90 0.90 1.9 1.9 0.90
Fan Motor
Locked rotor amps 4.1 4.1 2.1 2.1 4.1 2.1 2.1
Rec. maximum fuse or circuit breaker size (amps) 60 40 20 15 60 40 15
*Minimum circuit ampacity 35.5 23.5 12.2 9.8 35.8 24.2 10.8
*Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
NOTE Extremes of operating range are plus 10% and minus 5% of line voltage.
ELECTRICAL DATA
Model No. HS29-012 HS29-018 HS29-024−2 HS29-024−3 HS29-030 HS29-036
Line voltage data 60 hz 208/230v
1ph
208/230v
1ph
208/230v
1ph
208/230v
1ph
208/230v
1ph
208/230
v
1ph
208/230v
3ph
460v
3ph
Rated load amps 4.9 8.6 7.9 12.2 14.7 16.0 10.3 5.1
Compressor Power factor .97 .97 .97 .96 .90 .91 .83 .83
Locked rotor amps 26.3 48.3 48.3 61.0 84.0 100.0 77.0 39.0
Condenser Coil
Full load amps 1.1 1.1 1.1 1.1 1.1 1.1 1.1 0.55
Fan Motor
Locked rotor amps 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.0
Rec. maximum fuse or circuit breaker size (amps) 15 20 15 25 30 35 20 10
*Minimum circuit ampacity 7.3 11.9 11.0 16.4 19.5 21.1 14.0 6.9
*Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
NOTE Extremes of operating range are plus 10% and minus 5% of line voltage.
ELECTRICAL DATA
Model No. HS29−042 HS29-048 HS29-060
Line voltage data 60 hz
208/230v
1ph
208/230v
3ph
460v
3ph
208/230v
1ph
208/230v
3ph
460v
3ph
575v
3ph
208/230v
1ph
208/230v
3ph
460v
3ph
575v
3ph
Rated load amps 20.3 12.4 6.4 23.7 12.8 6.4 5.1 28.8 15.4 7.6 5.9
Compressor Power factor .84 .93 .93 .98 .88 .88 .88 .95 0.86 0.86 0.86
Locked rotor amps 127.0 88.0 44.0 129.0 91.0 46.0 37.0 169.0 124.0 59.6 49.4
Condenser
Full load amps 1.1 1.1 .55 1.9 1.9 0.9 0.9 1.9 1.9 0.90 0.90
Coil
Fan Motor
Locked rotor amps 1.9 1.9 1.0 4.1 4.1 2.1 2.1 4.1 4.1 2.1 2.1
Rec. maximum fuse or circuit breaker
size (amps)
40 25 15 50 30 15 10 60 35 15 10
*Minimum circuit ampacity 26.4 16.6 8.6 31.5 17.9 8.9 7.3 37.9 21.2 10.4 8.3
*Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
NOTE Extremes of operating range are plus 10% and minus 5% of line voltage.
