Lennox HS40 Series

Page 9
TABLE 3
R407C Saturated Liquid Temperature and Pressure Chart
Use this chart for subcooling only, not superheat
Saturated Liquid
Liquid Line Pressure
Saturated Liquid
Liquid Line Pressure
S
aturate
d
Li
qu
id
Temperature °C
R407C
Psig (kPa)
R22
Psig (kPa)
S
aturate
d
Li
qu
id
Temperature °C
R407C
Psig (kPa)
R22
Psig (kPa)
15 116 (799) 102 (703) 33 197 (1358) 174 (1199)
16 118 (813) 104 (717) 33 200 (1378) 176 (1213)
16 120 (827) 105 (723) 34 203 (1399) 179 (1234)
17 123 (848) 107 (737) 35 206 (1420) 182 (1254)
17 125 (861) 109 (751) 35 210 (1447) 184 (1268)
18 127 (875) 111 (765) 36 213 (1468) 187 (1289)
18 129 (889) 113 (779) 36 216 (1489) 190 (1310)
19 131 (903) 115 (792) 37 219 (1509) 193 (1330)
20 134 (923) 117 (806) 37 222 (1530) 196 (1351)
20 136 (937) 119 (820) 38 226 (1558) 199 (1372)
21 138 (951) 121 (834) 38 229 (1578) 202 (1392)
21 141 (972) 123 (848) 39 232 (1599) 205 (1413)
22 143 (985) 126 (868) 40 236 (1627) 208 (1431)
22 146 (1006) 128 (882) 40 239 (1647) 211 (1454)
23 148 (1020) 130 (896) 41 242 (1668) 214 (1475)
23 151 (1041) 132 (910) 41 246 (1696) 217 (1496)
24 153 (1054) 134 (923) 42 249 (1716) 220 (1516)
25 156 (1075) 137 (944) 42 253 (1744) 223 (1537)
25 158 (1089) 139 (958) 43 257 (1771) 226 (1558)
26 161 (1110) 141 (972) 43 260 (1792) 229 (1578)
26 163 (1123) 144 (992) 44 264 (1820) 233 (1606)
27 166 (1144) 146 (1006) 45 268 (1847) 236 (1627)
27 169 (1165) 148 (1020) 45 271 (1868) 239 (1647)
28 171 (1179) 151 (1041) 46 275 (1896) 243 (1675)
28 174 (1199) 153 (1054) 47 279 (1923) 246 (1696)
29 177 (1220) 156 (1075) 47 283 (1951) 250 (1723)
30 180 (1241) 158 (1089) 47 287 (1978) 253 (1744)
30 183 (1261) 161 (1110) 48 290 (1999) 256 (1765)
31 186 (1282) 163 (1123) 48 294 (2027) 260 (1792)
31 188 (1296) 166 (1144) 51 315 (2171) 278 (1916)
32 191 (1316) 168 (1158) 54 336 (2316) 297 (2047)
32 194 (1337) 171 (1179) 57 358 (2468) 317 (2185)
