Page 12
LGA PARTS ARRANGEMENT
FIGURE 1
HEAT EXCHANGER
EVAPORATOR COIL
FILTER
ECONOMIZER
(OPTIONAL)
DISCONNECT
(OPTIONAL)
120V GFI OUTLET
(OPTIONAL)
BLOWER
BURNERS
GAS VALVE
COMBUSTION AIR
BLOWER
COMPRESSOR
CONDENSER FAN
CONTROL PANEL
LCA PARTS ARRANGEMENT
FIGURE 2
EVAPORATOR COIL
FILTERS
ECONOMIZER
(OPTIONAL)
DISCONNECT
(OPTIONAL)
120V GFI OUTLET
(OPTIONAL)
BLOWER
ELECTRICAL HEAT
(OPTIONAL)
COMPRESSOR
CONTROL PANEL
CONDENSER FAN
FUSE BOX
(ELECTRIC HEAT ONLY)
