Page 32
5
7
8
6
9
10
J2 P2
F
I
G
U
R
E
2
4
ELECTRIC HEAT SECTION
WIRE
TIES
ELECTRIC ELEMENT
/CONTROL ASSEMBLY
EHAFB FUSE BOX
F4 F3 F3
FIGURE 25
PARTS ARRANGEMENT FOR ELECTRIC HEAT SECTION
EHA SERIES UNITS 3 THROUGH 5 TONS,
EHA060-15-1P SHOWN
Contactor K15
Contactor K16
Contactor K17
(EHA060-15/20/25-1P ONLY)
Primary Switch S15
Secondary Switch S20
Secondary Switch S20
Secondary Switch S20
