IMC BOARD INPUTS AND OUTPUTS
FIGURE 7
P110
P111
P112
P113
P114
P115
P116
SENSORS
INPUTS
OUTPUTS
COMPRESSOR
SAFETY INPUTS
BURNER
INPUTS
ROOM
THERMOSTAT
(A2)
A55
A56
A57
A58
P117
A60
P120
A59
OR
IMC AND ADD−ON BOARD LOCATION AND OPERATION
A55:
A56:
Optional
Economizer
and/or Power
Exhaust Fan
A57
(LCA / LGA):
Second
compressor
1 Outdoor fan
A58:
Second Gas
Valve
A60:
Second Electric
Heat Section
A59 (LCA / LGA):
Compressors 3
and 4 and Outdoor
Fans (4)
or
1 Blower
1 Compressor
1 Outdoor fan
1 Gas valve
1 Reversing valve
1 Electric heat section
TB1 connects to P110. Room thermostat connects to TB1. See section C2 in
the wiring diagram section P.65
