Page 43
FIGURE 15
BURNER
COMBUSTION
AIR INDUCER
(B15)
VENT
CONNECTOR
GAS VALVE
(GV3)
HEAT
EXCHANGER
TUBE
FIGURE 16
FLAME ROLLOUT
LIMIT S69
GAS
VALVE
GV3
BURNERS
COMBUSTION
AIR INDUCER
B15
HEAT EXCHANGER TUBE
