Page 9
ELECTRICAL/ELECTRIC HEAT DATA LGA/LCA
21 TON HIGH EFFICIENCY (R−22) 248H2
Voltage − 60hz − 3 phase
208/230V 460V 575V
Indoor Blower Motor Horsepower 5 7.5 10 5 7.5 10 5 7.5 10
4
Electric Heat Control Kit 15K13 15K92 15K93
Disconnect with Standard
PEF
0 kW 84M14 84M14 84M14 84M13 84M13 84M13 84M13 84M13 84M13
30 kW 84M14 84M14 84M14 84M13 84M13 84M13 84M13 84M13 84M13
45 kW 84M15 84M15 84M15 84M13 84M13 84M14 84M13 84M13 84M13
60 kW 84M15 84M15 84M15 84M14 84M14 84M14 84M13 84M14 84M14
90 kW N/A N/A N/A 84M14 84M14 84M14 84M14 84M14 84M14
120 kW N/A N/A N/A 84M15 84M15 84M15 84M14 84M14 84M14
with 50%
High Static PEF
0 kW 84M14 84M14 84M14 84M13 84M13 84M13 84M13 84M13 84M13
30 kW 84M14 84M14 84M14 84M13 84M13 84M13 84M13 84M13 84M13
45 kW 84M15 84M15 84M15 84M13 84M14 84M14 84M13 84M13 84M13
60 kW 84M15 84M15 84M15 84M14 84M14 84M14 84M13 84M14 84M14
90 kW N/A N/A N/A 84M14 84M14 84M14 84M14 84M14 84M14
120 kW N/A N/A N/A 84M15 84M15 84M15 84M14 84M14 84M15
with 100%
High Static PEF
0 kW 84M14 84M14 84M15 84M13 84M13 84M13 84M13 84M13 84M13
30 kW 84M14 84M14 84M15 84M13 84M13 84M13 84M13 84M13 84M13
45 kW 84M15 84M15 84M15 84M14 84M14 84M14 84M13 84M13 84M13
60 kW 84M15 84M15 84M15 84M14 84M14 84M14 84M14 84M14 84M14
90 kW N/A N/A N/A 84M14 84M14 84M15 84M14 84M14 84M14
120 kW N/A N/A N/A 84M15 84M15 84M15 84M14 84M15 84M15
without power exhaust 84M14 84M14 84M14 84M13 84M13 84M13 84M13 84M13 84M13
Terminal
Block
with Standard
PEF
0 kW LTB2−175 LTB2−175 LTB2−175 LTB2−175 LTB2−175
30 kW LTB2−175 LTB2−175 LTB2−175 LTB2−175 LTB2−175
45 kW LTB2−175 LTB2−175 LTB2−335 LTB2−175 LTB2−175
60 kW LTB2−175 LTB2−335 LTB2−335 LTB2−175 LTB2−175
90 kW LTB2−335 LTB2−335 LTB2−335 LTB2−175 LTB2−175
120 kW LTB2−335 LTB2−335 LTB2−335 LTB2−175 LTB2−175
with 50%
High Static PEF
0 kW LTB2−175 LTB2−175 LTB2−175 LTB2−175 LTB2−175
30 kW LTB2−175 LTB2−175 LTB2−175 LTB2−175 LTB2−175
45 kW LTB2−175 LTB2−335 LTB2−335 LTB2−175 LTB2−175
60 kW LTB2−335 LTB2−335 LTB2−335 LTB2−175 LTB2−175
90 kW LTB2−335 LTB2−335 LTB2−335 LTB2−175 LTB2−175
120 kW LTB2−335 LTB2−335 LTB2−335 LTB2−175 LTB2−175
with 100%
High Static PEF
0 kW LTB2−175 LTB2−175 LTB2−175 LTB2−175 LTB2−175
30 kW LTB2−175 LTB2−175 LTB2−175 LTB2−175 LTB2−175
45 kW LTB2−335 LTB2−335 LTB2−335 LTB2−175 LTB2−175
60 kW LTB2−335 LTB2−335 LTB2−335 LTB2−175 LTB2−175
90 kW LTB2−335 LTB2−335 LTB2−335 LTB2−175 LTB2−175
120 kW LTB2−335 LTB2−335 LTB2−335 LTB2−175 LTB2−175
without power exhaust LTB2−175 LTB2−175 LTB2−175 LTB2−175 LTB2−175
5
Unit Fuse
Block
with Standard PEF LAFB
125A4
LAFB
125A4
LAFB
150A3
LAFB
60A8
LAFB
70A8
LAFB
70A8
LAFB
50A8
LAFB
50A8
LAFB
60A8
with 50% High Static PEF LAFB
125A4
LAFB
150A3
LAFB
150A3
LAFB
70A8
LAFB
70A8
LAFB
80A6
LAFB
50A8
LAFB
60A8
LAFB
60A8
with 100% High Static PEF LAFB
150A3
LAFB
150A3
LAFB
175A3
LAFB
70A8
LAFB
70A8
LAFB
80A6
LAFB
60A8
LAFB
60A8
LAFB
60A8
without power exhaust LAFB
110A4
LAFB
125A4
LAFB
150A3
LAFB
60A8
LAFB
60A8
LAFB
70A8
LAFB
45A8
LAFB
50A8
LAFB
50A8
4
Electric Heat Control module only for use with 45 kW or more of electric heat.
5
Only for use with electric heat.
