Lennox LCH Series Installation Instructions

Page 41
BLOWER DATA - LCH BELT DRIVE - 6 TON - HIGH EFFICIENCY
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (heat section, economizer, etc.).
2 - Any eld installed accessories air resistance (duct resistance, diffuser, etc.).
See Page 45 for blower motors and drives and wet coil and options/accessory air resistance data.
HORIZONTAL
Air
Volume
(cfm)
External Static (in.w.g.)
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.9 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1900 507 0.55 538 0.58 571 0.6 604 0.63 639 0.66 673 0.7 707 0.74 740 0.78 772 0.82 802 0.86
2000 522 0.59 554 0.62 586 0.64 620 0.67 653 0.71 687 0.74 720 0.78 752 0.82 783 0.87 812 0.91
2100 539 0.63 571 0.66 603 0.69 636 0.72 669 0.75 702 0.79 734 0.83 765 0.88 795 0.92 823 0.97
2200 557 0.68 588 0.71 620 0.74 652 0.77 685 0.81 717 0.84 748 0.89 778 0.93 807 0.98 834 1.03
2300 576 0.73 607 0.76 638 0.79 670 0.83 701 0.86 733 0.9 763 0.95 792 0.99 820 1.04 846 1.09
2400 596 0.79 626 0.82 657 0.85 688 0.89 718 0.92 749 0.96 778 1.01 806 1.06 833 1.11 858 1.16
2500 616 0.85 645 0.88 676 0.91 706 0.95 736 0.99 765 1.03 794 1.08 821 1.13 847 1.18 871 1.23
2600 636 0.91 665 0.94 695 0.98 724 1.02 754 1.06 782 1.1 809 1.15 836 1.2 861 1.25 885 1.3
2700 657 0.97 685 1.01 714 1.04 743 1.08 771 1.13 799 1.17 826 1.22 851 1.27 875 1.32 899 1.37
2800 677 1.03 706 1.07 734 1.11 762 1.16 790 1.2 816 1.25 842 1.3 867 1.35 890 1.4 913 1.45
2900 698 1.1 726 1.14 754 1.19 781 1.23 808 1.28 834 1.33 859 1.38 883 1.43 906 1.48 928 1.54
Air
Volume
(cfm)
External Static (in.w.g.)
1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1900 830 0.91 857 0.95 883 0.99 910 1.04 937 1.09 964 1.13 991 1.18 1017 1.23 1042 1.28 1067 1.34
2000 839 0.96 865 1 891 1.05 917 1.09 944 1.14 970 1.19 996 1.24 1022 1.29 1047 1.34 1071 1.4
2100 849 1.02 874 1.06 900 1.11 926 1.15 952 1.2 978 1.25 1003 1.3 1028 1.35 1052 1.41 1075 1.46
2200 860 1.08 885 1.12 910 1.17 935 1.21 960 1.26 986 1.31 1010 1.36 1034 1.42 1058 1.48 1081 1.53
2300 871 1.14
895 1.19 920 1.23 945 1.28 969 1.33 994 1.38 1018 1.43 1042 1.49 1065 1.55 1087 1.61
2400 883 1.21 907 1.25 931 1.3 955 1.35 979 1.4 1003 1.45 1027 1.51 1050 1.57 1072 1.63 1094 1.69
2500 895 1.28 919 1.32 942 1.37 966 1.42 990 1.48 1013 1.53 1036 1.59 1059 1.65 1081 1.71 1102 1.78
2600 908 1.35 931 1.4 955 1.45 978 1.5 1001 1.56 1024 1.62 1046 1.68 1068 1.74 1089 1.8 1110 1.87
2700 922 1.43 945 1.48 967 1.53 990 1.59 1013 1.65 1035 1.71 1056 1.77 1078 1.84 1099 1.9 1119 1.96
2800 936 1.51 958 1.56 980 1.62 1003 1.68 1025 1.74 1046 1.8 1067 1.87 1088 1.93 1109 2 1129 2.06
2900 950 1.6 972 1.66 994 1.72 1016 1.78 1037 1.84 1058 1.91 1079 1.97 1099 2.04 1119 2.11 1139 2.17
