Page 49
FIGURE 20
ELECTRIC HEAT
PRIMARY ELECTRIC
HEAT LIMIT
S15
HEATING ELEMENTS
HE1 - HE6
P2
CONTROL WIRE
HARNESS
ELECTRIC HEAT
VESTIBULE
SECONDARY
LIMIT S20
ELECTRIC
HEAT THERMOSTAT
S19
SECONDARY
LIMIT S20
SECONDARY
LIMIT S20
SECONDARY
LIMIT S20
SECONDARY
LIMIT S20
SECONDARY
LIMIT S20
FIGURE 21
ELECTRIC HEAT
FUSE F3
F3-2
TERMINAL STRIP
(TB3)
FIRST STAGE ELECTRIC
HEAT CONTACTOR K15
SECOND STAGE ELECTRIC
HEAT CONTACTOR K16
FUSE F3
F3 ‐ 1
FUSE F42
F42 ‐ 1
FUSE F42
F42 ‐ 2
