Page 17
BLOWER DATA 1.0 HP
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (heat section, economizer, etc.).
2 - Any eld installed accessories air resistance (duct resistance, di󰀨user, etc.).
Minimum Air Volume Required For Di󰀨erent Gas Heat Sizes:
Standard Heat - 1075 cfm; Medium Heat - 1150 cfm; High Heat - 1500 cfm
See page 20 for wet coil and options/accessory air resistance data.
DOWNFLOW
External
Static
Press.
in. w.g.
Percentage of Total Motor Torque
20% 30% 40% 50% 60% 70% 80% 90% 100%
Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM
0 1067 112 488 1325 196 573 1583 279 657 1759 381 726 1934 482 794 2046 579 845 2157 676 896 2285 816 956 2358 925 989
0.1 984 97 537 1249 184 616 1513 270 695 1697 376 760 1881 481 825 2002 584 873 2123 686 921 2273 838 978 2352 947 1008
0.2 912 91 587 1183 180 661 1453 268 735 1644 377 796 1835 486 856 1964 593 902 2093 700 947 2264 863 1001 2349 973 1030
0.3 851 92 636 1126 183 706 1400 273 775 1597 385 832 1794 497 889 1931 607 932 2067 717 974 2256 891 1026 2348 1001 1053
0.4 797 100 687 1075 192 751 1353 283 815 1555 397 869 1757 511 922 1901 625 962 2044 738 1002 2248 919 1051 2347 1031 1077
0.5 752 114 737 1032 206 796 1312 298 855 1518 413 905 1724 528 955 1873 644 993 2021 760 1030 2239 948 1078 2345 1061 1102
0.6 712 132 787 994 224 842 1275 316 896 1484 432 942 1692 548 988 1845 666 1024 1998 783 1059 2228 977 1104 - - - - - - - - -
0.7 678 155 836 960 246 886 1242 336 936 1452 452 979 1662 568 1021 1818 687 1055 1974 806 1088 2214 1004 1131 - - - - - - - - -
0.8 648 180 885 929 269 931 1210 358 976 1421 474 1016 1632 589 1055 1790 709 1086 1948 828 1117 2195 1028 1158 - - - - - - - - -
0.9 621 207 933 900 294 974 1179 381 1015 1390 495 1051 1600 609 1087 1760 728 1117 1919 847 1146 2170 1049 1185 - - - - - - - - -
1.0 596 235 981 872 319 1017 1148 403 1053 1357 516 1086 1566 628 1119 1725 746 1147 1884 864 1174 2139 1066 1212 - - - - - - - - -
1.1 - - - - - - - - - - - - - - - - - - 1115 424 1090 1322 534 1120 1528 643 1150 1686 760 1176 1844 876 1201 2100 1078 1238 - - - - - - - - -
1.2 - - - - - - - - - - - - - - - - - - 1080 443 1126 1283 549 1153 1485 655 1180 1641 770 1204 1797 884 1228 2052 1083 1264 - - - - - - - - -
1.3 - - - - - - - - - - - - - - - - - - 1040 458 1161 1238 561 1185 1436 663 1209 1589 775 1231 1742 886 1253 1993 1081 1288 - - - - - - - - -
1.4 - - - - - - - - - - - - - - - - - - 996 469 1194 1189 567 1215 1381 665 1236 1530 773 1257 1678 881 1277 1923 1071 1311 - - - - - - - - -
HORIZONTAL
External
Static
Press.
in. w.g.
Percentage of Total Motor Torque
20% 30% 40% 50% 60% 70% 80% 90% 100%
Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM
0 1087 111 493 1304 184 579 1520 257 665 1689 368 738 1857 478 810 1972 588 864 2087 698 918 2196 844 975 2283 925 1000
0.1 1021 104 537 1246 180 618 1470 255 699 1646 368 768 1821 480 837 1941 592 888 2061 704 938 2179 852 992 2255 926 1017
0.2 961 102 582 1193 181 658 1425 259 734 1607 373 799 1789 487 864 1914 601 912 2039 714 960 2163 864 1012 2231 932 1034
0.3 906 106 628 1145 186 699 1384 266 769 1572 382 831 1759 498 892 1889 613 938 2018 728 984 2149 879 1033 2209 941 1053
0.4 855 113 674 1101 196 740 1347 278 806 1540 396 864 1732 513 921 1866 629 965 1999 744 1008 2134 896 1054 - - - - - - - - -
0.5 808 125 720 1060 209 781 1312 293 842 1509 412 896 1706 530 950 1843 646 992 1980 762 1033 2119 915 1077 - - - - - - - - -
0.6 764 139 766 1022 225 823 1279 310 879 1481 430 930 1682 549 980 1821 666 1019 1960 782 1058 2102 935 1101 - - - - - - - - -
0.7 722 155 812 985 242 864 1247 328 916 1452 449 964 1657 569 1011 1799 686 1048 1940 803 1084 2084 955 1125 - - - - - - - - -
0.8 682 172 858 949 260 906 1216 348 953 1424 469 997 1632 589 1041 1776 706 1076 1919 823 1111 2063 974 1150 - - - - - - - - -
0.9 643 191 903 914 279 946 1185 367 989 1396 489 1030 1606 610 1071 1751 727 1104 1895 843 1137 2039 992 1175 - - - - - - - - -
1.0 - - - - - - - - - - - - - - - - - - 1153 386 1024 1366 508 1062 1579 629 1100 1724 745 1132 1869 861 1163 2011 1008 1201 - - - - - - - - -
1.1 - - - - - - - - - - - - - - - - - - 1120 404 1059 1334 525 1095 1548 646 1130 1694 761 1160 1839 876 1189 1979 1021 1226 - - - - - - - - -
1.2 - - - - - - - - - - - - - - - - - - 1085 420 1093 1300 541 1126 1515 661 1158 1660 775 1186 1805 889 1214 1941 1031 1250 - - - - - - - - -
1.3 - - - - - - - - - - - - - - - - - - 1047 433 1126 1263 553 1156 1478 672 1186 1622 785 1213 1766 898 1239 1897 1037 1275 - - - - - - - - -
1.4 - - - - - - - - - - - - - - - - - - 1005 442 1158 1221 561 1185 1436 680 1212 1579 792 1238 1721 903 1263 1847 1037 1298 - - - - - - - - -
