LF24 − 100,000 to 400,000 Btuh / Page 7
ACCESSORY DIMENSIONS − INCHES (MM)
60 deg
A
23−1/2
(597)
28−3/4
(730)
A
30−7/8
(784)
31−3/4(
806)
30 deg
A
25−3/16
(640)
18−1/4
(464)
27−7/8
(708)
45 deg
A
28−1/8
(714)
30_ Discharge Nozzle
90_ Discharge Nozzle60_ Discharge Nozzle
45_ Discharge Nozzle
25−3/16
(640)
18
(457)
25−3/16
(640)
25−3/16
(640)
Model Usage
A
in. mm
LF24−100
LF24−115
18−1/4 464
LF24−145
LF24−175
LF24−200
21−1/4 540
LF24−230
LF24−250
LF24−300
LF24−345
LF24−400
39−1/4 997
