Lennox LGA Series User Manual

Page 50
TABLE 5
LCA / LCC ELECTRIC HEAT SECTION FUSE RATING
EHA QUANTITY
& SIZE
VOLTAGES
FUSE (3 each)
F3 − 1 F3 − 2 F3 − 3 F3 − 4 F3 − 5 F3 − 6 F3 − 7 F3 − 8
(1) EHA360−15 &
(1) EHA360S−15
(30 kW Total)
or
(1) EHA156−15 &
(1) EHA156S−15
208/230V
60 Amp
250V
60 Amp
250V
−−−−− −−−−− −−−−− −−−−− −−−−− −−−−−
460V
50 Amp
600V
−−−−− −−−−− −−−−− −−−−− −−−−− −−−−− −−−−−
575V
40 Amp
600V
−−−−− −−−−− −−−−− −−−−− −−−−− −−−−− −−−−−
(2) EHA360−22.5
(45 kW Total)
or
(2) EHA156−22.5
208/230V
50 Amp
250V
−−−−− −−−−−
25 Amp
250V
50 Amp
250V
−−−−− −−−−−
25 Amp
250V
460V
25 Amp
600V
−−−−− −−−−−
15 Amp
600V
25 Amp
600V
−−−−− −−−−−
15 Amp
600V
575V
20 Amp
600V
−−−−− −−−−−
10 Amp
600V
20 Amp
600V
−−−−− −−−−−
10 Amp
600V
(2) EHA150−30
(60 kW Total)
or
(2) EHA156−30
208/230V
50 Amp
250V
−−−−− −−−−−
50 Amp
250V
50 Amp
250V
−−−−− −−−−−
50 Amp
250V
460V
25 Amp
600V
−−−−− −−−−−
25 Amp
600V
25 Amp
600V
−−−−− −−−−−
25 Amp
600V
575V
20 Amp
600V
−−−−− −−−−−
20 Amp
600V
20 Amp
600V
−−−−− −−−−−
20 Amp
600V
(2) EHA360−45
(90 kW Total)
208/230V
50 Amp
250V
−−−−−
60 Amp
250V
60 Amp
250V
50 Amp
250V
−−−−−
60 Amp
250V
60 Amp
250V
460V
25 Amp
600V
−−−−− −−−−−
50 Amp
600V
25 Amp
600V
−−−−− −−−−−
50 Amp
600V
575V
20 Amp
600V
−−−−− −−−−−
40 Amp
600V
20 Amp
600V
−−−−− −−−−−
40 Amp
600V
(2) EHA150−60
(120 kW Total)
208/230V
60 Amp
250V
60 Amp
250V
60 Amp
250V
60 Amp
250V
60 Amp
250V
60 Amp
250V
60 Amp
250V
60 Amp
250V
460V
50 Amp
600V
−−−−− −−−−−
50 Amp
600V
50 Amp
600V
−−−−− −−−−−
50 Amp
600V
575V
40 Amp
600V
−−−−− −−−−−
40 Amp
600V
40 Amp
600V
−−−−− −−−−−
40 Amp
600V
FIGURE 29
EHA 30, 45, 60, 90 and 120 KW
ELECTRIC HEAT SECTION PARTS ARRANGEMENT
PRIMARY ELECTRIC
HEAT LIMIT
S15(1
ST
SECTION)
S107(2
nd
SECTION)
HEATING ELEMENTS
HE1 − HE14
CONTROL WIRE
HARNESS
ELECTRIC HEAT
VESTIBULE
