Page 29
COMBUSTION AIR
BLOWER
EVAPORATOR
COIL
CONDENSER FANS
COMPRESSORS
BURNERS
HEAT
EXCHANGER TUBES
BLOWERS
FILTERS
(12 20 X 20 X 2 in.
[508 X 508X 51mm])
ECONOMIZER
DAMPERS (OPTIONAL)
CONTROL BOX
LGA/LGC PARTS ARRANGEMENT
FIGURE 1
ELECTRIC HEAT
(Optional)
EVAPORATOR
COIL
CONDENSER FANS
COMPRESSORS
BLOWERS
ECONOMIZER
DAMPERS (OPTIONAL)
CONTROL BOX
FIGURE 2
LCA/LCC PARTS ARRANGEMENT
FILTERS
(12 20 X 20 X 2 in.
[508 X 508X 51mm])
