BLOWER DATA 3 & 4 TON
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE. FOR ALL UNITS ADD: 1 - Any factory installed options air resistance (heat section, economizer, etc.). 2 - Any eld installed accessories air resistance (duct resistance, di󰀨user, etc.). See Page 19 for blower motors and drives and wet coil and options/accessory air resistance data. DOWNFLOW
Total
Air
Volume
cfm
Total Static Pressure - in. w.g.
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1 1.2 1.3
RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts
400 686 18 789 39 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
500 761 33 860 52 957 68 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
600 840 46 937 64 1031 80 1112 91 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
- - - - - - - - -
700 926 60 1020 77 1110 92 1190 105 1258 117 1319 131 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
800 1022 73 1110 90 1195 105 1272 119 1338 133 1399 148 1460 166 1523 184 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
900 1126 88 1207 104 1286 119 1358 135 1421 150 1480 168 1539 187 1599 207 1660 227 1719 250 - - - - - - - - - - - - - - - - - -
1000 1237 103 1310 120 1381 136 1447 153 1507 171 1564 190 1619 211 1676 232 1733 255 1788 280 1836 306 1879 332 - - - - - -
1100 1352 120 1417 138 1481 156 1541 174 1597 194 1650 216 1703 238 1757 262 1810 287 1860 312 1905 339
1946 365 1986 391
1200 1468 141 1527 159 1583 179 1637 200 1688 222 1739 246 1789 271 1839 296 1888 321 1935 348 1977 375 2016 401 2055 426
1300 1584 164 1636 185 1687 206 1736 230 1783 255 1829 281 1877 306 1924 332 1969 359 2011 386 2051 412 2088 438 2126 462
1400 1697 191 1744 215 1790 240 1834 266 1877 293 1920 320 1964 346 2007 371 2048 398 2088 424 2126 449 2163 474 2201 498
1500 1802 227 1846 253 1888 280 1930 308 1970 336 2010 361 2049 386 2089 410 2128 436 2166 461 2204 486 2241 511 2279 536
1600 1903 271 1944 298 1984 326 2024 354 2062 380 2100 403 2137 426 2174 448 2211 474 2248 499 2285
525 2322 553 2359 582
1700 2007 319 2045 346 2083 373 2120 399 2157 423 2193 445 2229 466 2264 489 2300 516 2336 544 2372 573 2407 604 2442 637
1800 2115 363 2151 390 2186 416 2221 442 2256 466 2291 488 2325 512 2359 538 2393 567 2428 599 2462 631 2496 666 2530 701
1900 2234 394 2265 422 2296 450 2328 478 2359 505 2391 533 2423 563 2455 595 2487 629 2520 664 2553 699 2587 735 2621 771
2000 2345 434 2371 466 2399 498 2426 530 2455 562 2484 595 2515 630 2545 667 2577 703 2609 739 2643 775 2678 810 2713 845
2100 2435 502 2459 537 2484 572 2511 606 2539 641 2569 676 2599 712 2631 748 2664 783 2697 818
2732 853 2768 887 2804 920
2200 2511 587 2535 623 2561 658 2588 694 2618 728 2650 762 2683 796 2716 830 2750 863 2785 897 2821 930 2857 963 2894 995
2300 2586 672 2612 707 2640 741 2669 776 2700 809 2734 842 2768 875 2802 908 2837 941 2873 974 2909 1007 2945 1039 2981 1071
Total
Air
Volume
cfm
Total Static Pressure - in. w.g.
1.4 1.5 1.6 1.7 1.8 1.9 2.0
RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts
1100 2028 415 2072 438 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1200 2095 449 2138 473 2183 497 2229 522 2274 550 - - - - - - - - - - - -
1300 2165 486 2206 510 2249 535 2293 562 2337 591 2381 620 2425 651
1400
2239 523 2279 549 2320 576 2361 605 2402 636 2443 668 2485 701
1500 2317 563 2355 592 2393 623 2432 656 2471 689 2509 723 2548 758
1600 2396 612 2432 645 2468 679 2505 714 2542 748 2579 783 2615 818
1700 2477 672 2512 707 2547 742 2583 777 2619 812 2655 846 2691 881
1800 2565 737 2599 772 2634 808 2670 842 2705 877 2741 911 2777 946
1900 2656 806 2691 841 2727 876 2762 911 2798 945 2833 979 2868 1013
2000 2749 879 2785 913 2820 947 2855 981 2890 1015 2925 1049 2959 1082
2100 2840 953 2876 987 2911 1020 2946 1053 2981 1087 3015 1121 3049 1154
2200 2930 1028 2965 1061 3000 1094 3035 1128 3069 1161 - - - - - - - - - - - -
2300 3017 1104 3052 1137 3087 1170 - - - - - - - - - - - - - - - - - - - - - - - -
