LGM092, 102, 120, 150 PARTS ARRANGEMENT
UNIT
CONTROLLER
EVAPORATOR
COIL
CONDENSER
FANS
CONDENSER
COIL
COMPRESSORS
CONDENSATE
DRAIN
FILTERS
(FOUR - 20 X 25 X 2”)
ECONOMIZER
(OPTIONAL)
BLOWER
(DIRECT DRIVE)
GAS VALVE
BURNERS
COMBUSTION
AIR INDUCER
IGNITION
CONTROL
REHEAT COIL
(OPTIONAL)
COMPRESSOR
INVERTER
(BEHIND THE
HINGED PANEL)
WIRELESS
BOARD
WIFI
ANTENNA
LCM092, 102, 120, 150 PARTS ARRANGEMENT
UNIT
CONTROLLER
EVAPORATOR
COIL
CONDENSER
FANS
CONDENSER
COIL
COMPRESSORS
CONDENSATE
DRAIN
FILTERS
(FOUR - 20 X 25 X 2”)
ECONOMIZER
(OPTIONAL)
BLOWER
(DIRECT DRIVE)
ELECTRIC HEAT
(OPTIONAL)
REHEAT COIL
(OPTIONAL)
COMPRESSOR
INVERTER
(BEHIND THE
HINGED PANEL)
WIRELESS
BOARD
WIFI
ANTENNA
