Page 52
LGT/LCT156, 180, 210, 240, 300
FIGURE 25
LGT/LCT56
EVAPORATOR / INDOOR COIL
(RT46, 47)
CLAMP THERMISTOR
TO BARE COPPER.
DETAILS NOT TO SCALE
YELLOW
RT46
BLUE
RT47
22J06
22J06
