Page 54
LGT/LCT156, 180, 210, 240, 300
FIGURE 27
CLAMP THERMISTOR
TO BARE COPPER.
DETAILS NOT TO SCALE
YELLOW
RT46
RED
RT50
BLUE
RT47
22J06
22J06
22J06
LGT/LCT180
EVAPORATOR / INDOOR COIL
RT46, 47, 50
