FIGURE 17
EHA 15, 30, 45, 60 and 90 KW
ELECTRIC HEAT SECTION PARTS
ARRANGEMENT
TRIC
HEAT LIMIT
S15(1
ST
SECTION)
S107(2
nd
SECTION)
HEATING ELEMENTS
HE1 - HE14
CONTROL WIRE
HARNESS
ELECTRIC HEAT
VESTIBULE
