7
(Display content or position may be different from above
graphics, please refer to actual products)
Parts name
Indoor Unit
air inlet
panel
aux.button
horizontal louver
air outlet
heating
indicator
temp.
indicator
cooling
indicator
power
indicator
receiver
window
drying
indicator
display
remote control
Outdoor Unit
Actual product may be different from above graphics, please refer to actual
products.
NOTICE:
air inlet
Connection wire
air outlet
