Service Manual
Installation and Maintenance
35
No.
Description
Part Code
QtyLNWR39X
Product Code CC052020401_K79014
1 Cabinet Assy 01431170 1
2 Condenser Assy 01101117 1
3 Axial Flow Fan 10331163 1
4 Rear Clapboard 01231502 1
5 Motor Support 1 01701605 1
6 Fan Motor 150116065 1
7 Top Cover Board Sub-assy 01251503 1
8 Front Clapboard Sub-Assy 01231804 1
9 Base Plate Of Air Flue 01221602 1
10 Propeller Housing 12101602 1
11 Air Outlet Sub-Assy 2000103601 1
12 Air Door Lever 10581601 1
13 Swing lever 10581602 1
14 Swing Lever2 10581021 1
15 SteppingMotor 1521211601 1
16 Swing Blade Support 10581603 1
17 Crank 73011001 1
18 Air Louver 10511601 2
19 Centrifugal fan Sub-Assy 10311501 1
20 Front Clapboard of Propeller housing 01231604 1
21 Evaporator Assy 01001292 1
22 Compressor and ttings 00101302 1
23 Compressor Gasket 76711043 3
24 Capillary Sub-Assy 03001970 1
25 4-Way Valve Assy 03021110 1
26 Magnet Coil 430004017 1
27 Water Tray 12411007 1
28 Chassis Sub-assy 0120122001P 1
29 Drainage Valve 07101001 1
30 Drainage Box 20181801 1
31 Cabinet Fastener 26251601 1
32 Chassis clamp 01211601 1
33 Power Cord 40020491 1
34 Electric Box Assy 20101432 1
35 Capacitor CBB61 33010037 1
36 Capacitor CBB65 33010743 1
37 Electric box 20111033 1
38 Main Board 30132091 1
39 Temperature Sensor 390000372 1
40 Temperature Sensor 390000451 1
41 Temperature Sensor 390000596 1
42 Display Board 30562019 1
43 LCD board(remote control) 20120037 1
44 Membrane 2243113201 1
45 Front Panel Assy 20001541_K79014 1
46 Guide blade lever 10581604 1
47 Guide blade 105116021 14
48 Front Case 20001601 1
49 Filter Sub-Assy 11121601 1
50 Front Panel Assy 20001541_K79014 1
51 Remote Controller 30510065_K79014 1
Above data is subject to change without notice.
