Service Manual
Installation and Maintenance
37
No.
Description
Part Code
QtyLNWR53X
Product Code CC052020500_K79014
1 Cabinet Assy 014316182 1
2 Condenser Assy 01101116 1
3 Axial Flow Fan 10331163 1
4 Rear Clapboard 01231099 1
5 Motor Support 1 01701605 1
6 Fan Motor 1501120707 1
7 Motor Support 2 01701604 1
8 Top Cover Board Sub-assy 01251611 1
9 Front Clapboard Sub-Assy 01231804 1
10 Base Plate Of Air Flue 01221602 1
11 Propeller Housing 12101602 1
12 Air Outlet Sub-Assy 2000103601 1
13 Air Door Lever 10581601 1
14 Swing lever 10581602 1
15 Swing Lever2 10581021 1
16 Step Motor 1521211601 1
17 Swing blade Support 10581603 1
18 Crank 73011001 1
19 Air Louver 10511601 2
20 Centrifugal Fan Sub-Assy 10311501 1
21 Front Clapboard of Propeller housing 01231604 1
22 Evaporator Assy 01001292 1
23 Compressor and ttings 00101300 1
24 Compressor Gasket 76812805 3
25 Capillary Sub-Assy 03001495 1
26 4-Way Valve Assy 03021227 1
27 Magnet Coil 430004017 1
28 Water Tray 12411007 1
29 Chassis Sub-assy 0120110701P 1
30 Drainage Valve 07101001 1
31 Drainage Box 20181801 1
32 Cabinet Fastener 26251601 1
33 Chassis clamp 01211601 1
34 Power Cord 400204911 1
35 Electric Box Assy 20101421 1
36 Capacitor CBB61 33010009 1
37 Capacitor CBB65 33000012 1
38 Electric box 20111033 1
39 Main Board 30132091 1
40 Ambient Temperature Sensor 390000451 1
41 Temperature Sensor 390000372 1
42 Temperature Sensor 390000451 1
43 Display Board 30562019 1
44 LCD board(remote control) 20120037 1
45 Membrane 2243113201 1
46 Front Panel Assy 20001541_K79014 1
47 Guide blade lever 10581604 1
48 Guide blade 105116021 14
49 Front Case 27220105253 1
50 Filter Sub-Assy 11121601 1
51 Front Panel 20001541_K79014 1
52 Remote Controller 30510065_K79014 1
Above data is subject to change without notice.
