Service Manual
Installation and Maintenance
39
No.
Description
Part Code
QtyLNWR59X
Product Code CC052020600_K79014
1 Cabinet Assy 01431118 1
2 Condenser Assy 01101118 1
3 Axial Flow Fan 10331163 1
4 Rear Clapboard 01231099 1
5 Motor Support 1 01701605 1
6 Fan Motor 1501120707 1
7 Motor Support 2 01701604 1
8 Top Cover Board Sub-assy 01251611 1
9 Soft Start Device 30116042 1
10 Electric Box 20111033 1
11 Capacitor CBB65 33000001 1
12 Electric Box Cover 20101237 1
13 Electric Box Sub-Assy 20101238 1
14 Front Clapboard Sub-Assy 012318041 1
15 Base Plate Of Air Flue 01221602 1
16 Propeller Housing 12101602 1
17 Air Outlet Sub-Assy 2000103601 1
18 Air Door Lever 10581601 1
19 Swing lever 10581602 1
20 Swing Lever2 10581021 1
21 Step Motor 1521211601 1
22 Swing blade Support 10581603 1
23 Crank 73011001 1
24 Air Louver 10511601 2
25 Centrifugal Fan Sub-Assy 10311501 1
26 Front Clapboard of Propeller housing 01231604 1
27 Evaporator Assy 01001100 1
28 Compressor and ttings 00101299 1
29 Compressor Gasket 76711043 3
30 Capillary Sub-Assy 03001498 1
31 4-Way Valve Assy 03021191 1
32 Magnet Coil 430004017 1
33 Water Tray 12411007 1
34 Chassis Sub-assy 0120110701P 1
35 Drainage Valve 07101001 1
36 Drainage Box 20181801 1
37 Cabinet Fastener 26251601 1
38 Chassis clamp 01211601 1
39 Power Cord 400204911 1
40 Electric Box Assy 20101480 1
41 Capacitor CBB61 33010009 1
42 Capacitor CBB65 33000001 1
43 Electric box 20111033 1
44 Main Board 30132092 1
45 Ambient Temperature Sensor 390000451 1
To Next Page
