Lennox M22A012S4-*P - Page 13

13
Table 4. Match-Ups
Outdoor
Model
No. of
Zones
Indoor Unit
Capacity
(Unit No.)
Line Set
Required
(Liquid x Gas)
MPA048S4M
MPB048S4M
Indoor Unit A
1/4” liq + 1/2” gas
Indoor Unit B
1/4” liq + 1/2” gas
Indoor Unit C
1/4” liq + 3/8” gas
Indoor Unit D
1/4” liq + 3/8” gas
Indoor Unit E
1/4” liq + 3/8” gas
3
009 (C) 1/4 in. x 3/8 in.
012 (B) 1/4 in. x 1/2 in.
024 (A)
2, 3
3/8 in. x 5/8 in.
3
009 (C) 1/4 in. x 3/8 in.
018 (A) 1/4 in. x 1/2 in.
018 (B) 1/4 in. x 1/2 in.
3
009 (C) 1/4 in. x 3/8 in.
018 (B) 1/4 in. x 1/2 in.
024 (A)
2, 3
3/8 in. x 5/8 in.
3
009 (C) 1/4 in. x 3/8 in.
024 (A)
2, 3
3/8 in. x 5/8 in.
024 (B)
2, 3
3/8 in. x 5/8 in.
3
012 (A) 1/4 in. x 1/2 in.
012 (B) 1/4 in. x 1/2 in.
012 (C)
1
1/4 in. x 1/2 in.
3
012 (B) 1/4 in. x 1/2 in.
012 (C)
1
1/4 in. x 1/2 in.
018 (A) 1/4 in. x 1/2 in.
3
012 (C) 1/4 in. x 1/2 in.
018 (A) 1/4 in. x 1/2 in.
018 (B)
1
1/4 in. x 1/2 in.
3
012 (B) 1/4 in. x 1/2 in.
012 (C)
1
1/4 in. x 1/2 in.
024 (A)
2, 3
3/8 in. x 5/8 in.
3
012 (B) 1/4 in. x 1/2 in.
018 (C)
1
1/4 in. x 1/2 in.
024 (A)
2, 3
3/8 in. x 5/8 in.
3
012 (C)
1
1/4 in. x 1/2 in.
024 (A)
2, 3
3/8 in. x 5/8 in.
024 (B)
2, 3
3/8 in. x 5/8 in.
3
018 (A) 1/4 in. x 1/2 in.
018 (B) 1/4 in. x 1/2 in.
018 (C)
1
1/4 in. x 1/2 in.
3
018 (B) 1/4 in. x 1/2 in.
018 (C)
1
1/4 in. x 1/2 in.
024 (A)
2, 3
3/8 in. x 5/8 in.
4
009 (A)
1
1/4 in. x 3/8 in.
009 (B)
1
1/4 in. x 3/8 in.
009 (C) 1/4 in. x 3/8 in.
009 (D) 1/4 in. x 3/8 in.
4
009 (B)
1
1/4 in. x 3/8 in.
009 (C) 1/4 in. x 3/8 in.
009 (D) 1/4 in. x 3/8 in.
012 (A) 1/4 in. x 1/2 in.
Table 4. Match-Ups
Outdoor
Model
No. of
Zones
Indoor Unit
Capacity
(Unit No.)
Line Set
Required
(Liquid x Gas)
MPA048S4M
MPB048S4M
Indoor Unit A
1/4” liq + 1/2” gas
Indoor Unit B
1/4” liq + 1/2” gas
Indoor Unit C
1/4” liq + 3/8” gas
Indoor Unit D
1/4” liq + 3/8” gas
Indoor Unit E
1/4” liq + 3/8” gas
4
009 (B)
1
1/4 in. x 3/8 in.
009 (C) 1/4 in. x 3/8 in.
009 (D) 1/4 in. x 3/8 in.
018 (A) 1/4 in. x 1/2 in.
4
009 (B)
1
1/4 in. x 3/8 in.
009 (C) 1/4 in. x 3/8 in.
009 (D) 1/4 in. x 3/8 in.
024 (A)
2, 3
3/8 in. x 5/8 in.
4
009 (C) 1/4 in. x 3/8 in.
009 (D) 1/4 in. x 3/8 in.
012 (A) 1/4 in. x 1/2 in.
012 (B) 1/4 in. x 1/2 in.
4
009 (C) 1/4 in. x 3/8 in.
009 (D) 1/4 in. x 3/8 in.
012 (B) 1/4 in. x 1/2 in.
018 (A) 1/4 in. x 1/2 in.
4
009 (C) 1/4 in. x 3/8 in.
009 (D) 1/4 in. x 3/8 in.
018 (A) 1/4 in. x 1/2 in.
018 (B) 1/4 in. x 1/2 in.
4
009 (C) 1/4 in. x 3/8 in.
009 (D) 1/4 in. x 3/8 in.
018 (B) 1/4 in. x 1/2 in.
024 (A)
2, 3
3/8 in. x 5/8 in.
4
009 (D) 1/4 in. x 3/8 in.
012 (A)
1
1/4 in. x 1/2 in.
012 (B)
1
1/4 in. x 1/2 in.
012 (C) 1/4 in. x 1/2 in.
