Lennox ML180UHE Simple Manual

ML180UHE / Page 2
WARRANTY
Duralok™ Aluminized Steel Heat Exchanger
- Limited twenty year warranty in residential
applications, ten years in non-residential applications.
All other covered components - Limited ve year
warranty in residential applications, one year in non-
residential applications.
Refer to Lennox Equipment Limited Warranty certicate
included with equipment for details.
APPROVALS
Units are Certied by AHRI.
Units tested and rated according to US DOE test
procedures and FTC labeling regulations.
“X” models approved by the California Energy
Commission and meet California Seasonal Efciency
requirements and California Nitrogen Oxides (NOx)
Standards.
ISO 9001 Registered Manufacturing Quality System.
Blower data from unit tests conducted in Lennox
Laboratory air test chamber.
APPLICATIONS
Input capacities of 44,000, 66,000, 88,000, 110,000 and
132,000 Btuh.
Energy efciency (AFUE) of 80%.
Compact cabinet for upow, horizontal-left or horizontal-
right applications.
Utility room, alcove, closet, crawl space, basement or
attic installation.
Lennox add-on indoor coils, high-efciency air cleaners
and humidiers can easily be added to furnace.
Shipped factory assembled with all controls installed
and wired.
Ready for installation in upow or horizontal right-hand
position without any modications. Horizontal left-hand
position requires repositioning of pressure switch.
Removable bottom seal panel shipped in place for side
return air is easily removed for bottom/end return air
applications.
Each unit factory test operated to ensure proper
operation.
FEATURES
Contents
Blower Data . . . . . . . . . . . . . . . . . . . . . . 13
Dimensions - Furnace/Coil Combined Dimensions . . 12
Dimensions - Horizontal Position . . . . . . . . . . . 10
Dimensions - Upow Position. . . . . . . . . . . . . 9
Features. . . . . . . . . . . . . . . . . . . . . . . . 2
Gas Heat Accessories . . . . . . . . . . . . . . . . 8
High Altitude Derate. . . . . . . . . . . . . . . . . . 8
Installation Clearances . . . . . . . . . . . . . . . . 7
Model Number Identication . . . . . . . . . . . . . 1
Optional Accessories . . . . . . . . . . . . . . . . . 8
Optional Accessory Dimensions . . . . . . . . . . . 11
Specications . . . . . . . . . . . . . . . . . . . . . 7
B
C
H
D
E
G
F
I
J
K
NOTE - ML180UHE FURNACES ARE NOT
AVAILABLE IN CANADA!
L

Lennox ML180UHE Specifications

General

Brand	Lennox
Model	ML180UHE
Category	Furnace
Language	English
