Page 11
FIGURE 3
INTEGRATED CONTROL
TERMINAL DESIGNATIONS
HUM -Humidifier (120VAC)
Line - Input (120VAC)
XFMR - Transformer (120VAC)
Cont - Continuous blower
EAC - Indoor Air Accessory (120VAC)
Cool - Cool Speed (120VAC)
Park 1 - Dead terminal for alternate speed tap
Park 2 - Dead terminal for alternate speed tap
HI Heat - High heat speed
LO Heat - Low heat speed
Heat Stage Jumper
(single stage shown)
Heat
Taps
Cool
Taps
Air Flow
Jumper
