BLOWER DATA
ML296UH110XV60C BLOWER PERFORMANCE (less lter)
BOTTOM RETURN AIR, RETURN AIR FROM BOTH SIDES OR RETURN AIR FROM BOTTOM AND ONE SIDE
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
“ADJUST”
Switch
Positions
Speed Switch Positions
Second Stage “HEAT” Speed - cfm Second Stage “COOL” Speed - cfm
D
1
C B A D C B
1
A
+ 1560 1760 1905 2080 1312 1560 1744 1955
1
NORM 1415 1610 1740 1930 1219 1405 1569 1796
— 1285 1485 1560 1745 1075 1272 1428 1634
“ADJUST”
Switch
Positions
First Stage “HEAT” Speed - cfm First Stage “COOL” Speed - cfm
D
1
C B A D C B
1
A
+ 1155 1325 1420 1565 937 1064 1247 1407
1
NORM 1055 1200 1310 1480 864 972 1146 1282
— 935 1075 1170 1315 790 888 1025 1167
1
Factory default jumper setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT speed position.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed
position. Continuous Fan Only speed is approximately 38% of the same second stage COOL speed position - minimum
500 cfm. Lennox Harmony III™ Zoning System Applications - Minimum blower speed is 478 cfm.
BLOWER DATA
ML296UH110XV60C BLOWER PERFORMANCE (less lter)
SINGLE SIDE RETURN AIR − Air volumes in bold (over 1800 cfm) require Optional Return Air Base and eld fabricated transition
to accommodate 20 x 25 x 1 in. air lter in order to maintain proper air velocity.
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
“ADJUST”
Switch
Positions
Speed Switch Positions
Second Stage “HEAT” Speed - cfm Second Stage “COOL” Speed - cfm
D
1
C B A D C B
1
A
+ 1530 1735 1845 2025 1270 1519 1712 1899
1
NORM 1380 1555 1705 1860 1170 1363 1555 1774
— 1235 1440 1540 1710 1059 1218 1401 1581
“ADJUST”
Switch
Positions
First Stage “HEAT” Speed - cfm First Stage “COOL” Speed - cfm
D
1
C B A D C B
1
A
+ 1140 1280 1390 1550 918 1053 1198 1366
1
NORM 1040 1175 1260 1430 820 964 1095 1231
— 910 1080 1150 1265 722 852 987 1116
1
Factory default jumper setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT speed position.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed
position. Continuous Fan Only speed is approximately 38% of the same second stage COOL speed position - minimum
500 cfm. Lennox Harmony III™ Zoning System Applications - Minimum blower speed is 478 cfm.
