3.2. Indoor Unit Specications (009 - 012 Ton) Units
* Indicates could be minor revision
1 or 2.
Model No.
MWMC006S4-*P MWMC009S4-*P MWMC012S4-*L MWMC012S4-*P
Nominal Tons
0.50 0.75 1 1
Power Supply - 60 hz - 1 phase
208/230V 115V 115V 208/230V
Rated load amps
0.25 0.2 0.2 0.25
Output (W)
20 20 20 20
Room Temperature
Range (°F)
Cooling
60 - 90 60 - 90 60 - 90 60 - 90
Heating
32 - 86 32 - 86 32 - 86 32 - 86
Air Volume - cfm (High/Medium/Low)
335/230/176 353/294/235 353/294/235 335/230/176
Sound Data (dBA) - Low/Medium/High
23/34/38 40.5/35/23.5 40.5/35/23.5 36/33.5/22.5
Piping Connections - Liquid/Gas - o.d. - are - in.
1/4 / 3/8 1/4 / 1/2 1/4 / 1/2 1/4 / 1/2
Drain connection o.d. - in.
1 1 1 1
Net/Shipping weights - lbs.
23 / 29 23 / 29 23 / 29 23 / 29
3.3. Indoor Unit Specications (018 - 030 Ton) Units
* Indicates could be minor revision 1 or
2.
Model No. MWMC018S4-*P MWMC024S4-*P MWMC030S4-*P
Nominal Tons 1.5 2 2.5
Power Supply - 60 hz - 1 phase 208/230V 208/230V 208/230V
Rated load amps 0.13 0.5 0.5
Output (W) 30 58 58
Room Temperature
Range (°F)
Cooling 60 - 90 60 - 90 60 - 90
Heating 32 - 86 32 - 86 32 - 86
Air Volume - cfm (High/Medium/Low)
524/76/306 611/414/319 646/505/382
Sound Data (dBA) - Low/Medium/High
46.5/43/32.5 44/39.5/34 46/40.5/33
Piping Connections - Liquid/Gas - o.d. - are - in. 1/4 / 1/2 3/8 / 5/8 3/8 / 5/8
Drain connection o.d. - in. 1 1 1
Net/Shipping weights - lbs. 27 / 36 44 / 55 44 / 55
3.4. Indoor Unit Specications (3WMC)
Indoor Unit Model No. 3WMC036S4
Nominal Tons
3
Power Supply - 60 hz - 1 phase
208/230V
Rated load amps
0.55
Output (W)
58
Room Temperature
Range (°F)
Cooling
60 - 90
Heating
32 - 86
Air Volume - cfm (High/Medium/Low)
639 / 506 / 382
Sound Data (dBA) - Low/Medium/High
47.5 / 42 / 35.5
Piping Connections - Liquid/Gas - o.d. - are - in.
3/8 / 5/8
Drain connection o.d. - in.
1
Shipping Data Net/Shipping weights - lbs.
44 / 55
