Table 5. MPC Multi-Zone System Combinations
NOTE - For multi-zone systems, the total capacity of all indoor units must be 66% to 133% of the outdoor unit capacity.
Outdoor Unit
Model No.
Number
of
Zones
Indoor Unit
Capacity
Nominal Cooling Capacity at Rated
System Capacity (Btuh)
Nominal Heating Capacity at Rated
System Capacity (Btuh)
#1 #2 #3 #4 #5 #1 #2 #3 #4 #5 #1 #2 #3 #4 #5
MPC036S4M 4
6K 6K 12K 24K - - - 4,700 4,700 9,400 18,900 - - - 5,000 5,000 10,000 19,900 - - -
6K 9K 9K 9K - - - 6,300 9,400 9,400 9,400 - - - 6,700 10,000 10,000 10,000 - - -
6K 9K 9K 12K - - - 6,000 9,000 9,000 12,000 - - - 6,400 9,500 9,500 12,700 - - -
6K 9K 9K 18K - - - 5,300 8,000 8,000 16,000 - - - 5,700 8,500 8,500 17,000 - - -
6K 9K 9K 24K - - - 4,700 7,100 7,100 18,900 - - - 5,000 7,500 7,500 19,900 - - -
6K 9K 12K 12K - - - 5,700 8,500 11,300 11,300 - - - 6,000 9,000 12,000 12,000 - - -
6K 9K 12K 18K - - - 5,000 7,500 10,100 15,100 - - - 5,300 8,000 10,600 15,900 - - -
6K 12K 12K 12K - - - 5,300 10,700 10,700 10,700 - - - 5,700 11,300 11,300 11,300 - - -
6K 12K 12K 18K - - - 4,700 9,400 9,400 14,100 - - - 5,000 10,000 10,000 14,900 - - -
9K 9K 9K 9K - - - 9,000 9,000 9,000 9,000 - - - 9,500 9,500 9,500 9,500 - - -
9K 9K 9K 12K - - - 8,500 8,500 8,500 11,300 - - - 9,000 9,000 9,000 12,000 - - -
9K 9K 9K 18K - - - 7,500 7,500 7,500 15,100 - - - 8,000 8,000 8,000 15,900 - - -
9K 9K 12K 12K - - - 8,000 8,000 10,700 10,700 - - - 8,500 8,500 11,300 11,300 - - -
9K 9K 12K 18K - - - 7,100 7,100 9,400 14,100 - - - 7,500 7,500 10,000 14,900 - - -
9K 12K 12K 12K - - - 7,500 10,100 10,100 10,100 - - - 8,000 10,600 10,600 10,600 - - -
12K 12K 12K 12K - - - 9,400 9,400 9,400 9,400 - - - 10,000 10,000 10,000 10,000 - - -
MPC048S4M
2
9K 24K - - - - - - - - - 9,000 24,000 - - - - - - - - - 9,400 25,100 - - - - - - - - -
9K 30K - - - - - - - - - 8,000 29,000 - - - - - - - - - 9,100 30,400 - - - - - - - - -
9K 36K - - - - - - - - - 8,000 33,000 - - - - - - - - - 8,600 34,500 - - - - - - - - -
12K 24K - - - - - - - - - 11,000 23,000 - - - - - - - - - 12,400 24,800 - - - - - - - - -
12K 30K - - - - - - - - - 11,000 28,000 - - - - - - - - - 11,900 29,600 - - - - - - - - -
12K 36K - - - - - - - - - 10,000 31,000 - - - - - - - - - 11,100 33,200 - - - - - - - - -
18K 18K - - - - - - - - - 17,000 17,000 - - - - - - - - - 18,600 18,600 - - - - - - - - -
18K 24K - - - - - - - - - 17,000 22,000 - - - - - - - - - 17,800 23,700 - - - - - - - - -
18K 30K - - - - - - - - - 15,000 26,000 - - - - - - - - - 16,600 27,600 - - - - - - - - -
18K 36K - - - - - - - - - 14,000 28,000 - - - - - - - - - 15,000 30,000 - - - - - - - - -
24K 30K - - - - - - - - - 18,000 23,000 - - - - - - - - - 20,000 25,000 - - - - - - - - -
24K 36K - - - - - - - - - 15,000 23,000 - - - - - - - - - 17,300 26,000 - - - - - - - - -
30K 30K - - - - - - - - - 19,000 19,000 - - - - - - - - - 21,700 21,700 - - - - - - - - -
3
6K 6K 24K - - - - - - 6,000 6,000 24,000 - - - - - - 6,400 6,400 25,500 - - - - - -
6K 6K 30K - - - - - - 6,000 6,000 29,000 - - - - - - 6,100 6,100 30,100 - - - - - -
6K 6K 36K - - - - - - 5,000 5,000 33,000 - - - - - - 5,800 5,800 34,300 - - - - - -
6K 9K 24K - - - - - - 6,000 9,000 23,000 - - - - - - 6,200 9,300 24,800 - - - - - -
6K 9K 30K - - - - - - 6,000 8,000 28,000 - - - - - - 5,900 8,800 29,300 - - - - - -
6K 9K 36K - - - - - - 5,000 8,000 32,000 - - - - - - 5,600 8,400 33,500 - - - - - -
6K 12K 18K - - - - - - 6,000 12,000 18,000 - - - - - - 6,400 12,800 19,100 - - - - - -
6K 12K 24K - - - - - - 6,000 11,000 23,000 - - - - - - 6,100 12,100 24,100 - - - - - -
6K 12K 30K - - - - - - 5,000 11,000 27,000 - - - - - - 5,800 11,500 28,600 - - - - - -
6K 12K 36K - - - - - - 5,000 10,000 31,000 - - - - - - 5,500 10,900 32,700 - - - - - -
6K 18K 18K - - - - - - 6,000 17,000 17,000 - - - - - - 6,100 18,100 18,100 - - - - - -
6K 18K 24K - - - - - - 5,000 16,000 22,000 - - - - - - 5,800 17,200 22,900 - - - - - -
6K 18K 30K - - - - - - 5,000 15,000 26,000 - - - - - - 5,500 16,400 27,300 - - - - - -
6K 18K 36K - - - - - - 5,000 14,000 29,000 - - - - - - 5,300 15,700 31,400 - - - - - -
6K 24K 24K - - - - - - 5,000 20,000 20,000 - - - - - - 5,500 21,800 21,800 - - - - - -
6K 24K 30K - - - - - - 5,000 19,000 24,000 - - - - - - 5,300 21,000 26,200 - - - - - -
9K 9K 18K - - - - - - 9,000 9,000 18,000 - - - - - - 9,600 9,600 19,100 - - - - - -
9K 9K 24K - - - - - - 9,000 9,000 23,000 - - - - - - 9,100 9,100 24,100 - - - - - -
9K 9K 30K - - - - - - 8,000 8,000 27,000 - - - - - - 8,600 8,600 28,600 - - - - - -
9K 9K 36K - - - - - - 8,000 8,000 31,000 - - - - - - 8,200 8,200 32,700 - - - - - -
9K 12K 12K - - - - - - 9,000 12,000 12,000 - - - - - - 9,900 13,200 13,200 - - - - - -
9K 12K 18K - - - - - - 9,000 12,000 18,000 - - - - - - 9,300 12,400 18,600 - - - - - -
9K 12K 24K - - - - - - 8,000 11,000 22,000 - - - - - - 8,800 11,800 23,500 - - - - - -
9K 12K 30K - - - - - - 8,000 11,000 26,000 - - - - - - 8,400 11,200 27,900 - - - - - -
9K 12K 36K - - - - - - 7,000 10,000 30,000 - - - - - - 8,100 10,700 32,100 - - - - - -
9K 18K 18K - - - - - - 8,000 17,000 17,000 - - - - - - 8,800 17,600 17,600 - - - - - -
