Lennox MPC User Manual

78
Table 10. MPC048S4M
Number of Zones and Outdoor Unit Connection Sizes
NOTE - Letter = Indoor Unit Zone Connection on Outdoor Unit
Zone 1 (A) Zone 2 (B) Zone 3 (C) Zone 4 (D) Zone 5 (E)
1/4 in. liq + 1/2 in. gas 1/4 in. liq + 1/2 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas
006 006 006 009 012
006 006 006 009 018
006 006 006 009 024
006 006 006 009 030
006 006 006 009 036
006 006 006 012 012
006 006 006 012 018
006 006 006 012 024
006 006 006 012 030
006 006 006 018 018
006 006 006 018 024
006 006 009 009 009
006 006 009 009 012
006 006 009 009 018
006 006 009 009 024
006 006 009 009 030
006 006 009 012 012
006 006 009 012 018
006 006 009 012 024
006 006 009 012 030
006 006 009 018 018
006 006 009 018 024
006 006 012 012 012
006 006 012 012 018
006 006 012 012 024
006 006 012 018 018
006 009 009 009 009
006 009 009 009 012
006 009 009 009 018
006 009 009 009 024
006 009 009 009 030
006 009 009 012 012
006 009 009 012 018
006 009 009 012 024
006 009 009 018 018
006 009 012 012 012
006 009 012 012 018
006 009 012 012 024
006 012 012 012 012
006 012 012 012 018
LEGEND:
CLEAR = No adapters required.
GRAY = 3/8 x 1/2 in. gas pipe adapter is required for line set connection to outdoor unit (furnished with outdoor unit).
BLACK = 1/4 x 3/8 in. liquid pipe adapter is required for line set connection to the 048 outdoor unit (furnished with outdoor unit).
1/2 x 5/8 in. gas pipe adapter is required for line set connection to the 048 outdoor unit (furnished with outdoor unit).
