The SmartWire
™
system is designed to simplify field wiring and sensor
installation.
1. Advanced connectors are color-coded, labeled and keyed to prevent
miswiring and ensure units are installed and set up correctly
• The wire-coloring scheme is standard across all units
• Each connection is intuitively labeled to simplify troubleshooting
