SLP98UHV Parts Identication
DURALOK
TM
HEAT
EXCHANGER
ASSEMBLY
BURNERS
VARIABLE SPEED
BLOWER
MOTOR
CABINET
GAS VALVE AND
MANIFOLD
VARIABLE SPEED
COMBUSTION AIR
INDUCER
FLUE
COLLAR
TOP CAP
SURELIGHT
®
INTEGRATED
CONTROL
PRESSURE SWITCH
ASSEMBLY
AIR INTAKE COLLAR
NOTE - This manual must be left with the equipment user.
Notice to Homeowner
This furnace is equipped with safety devices that protect
you and your property. If one or more of these devices
is activated, furnace operation will stop. If your home is
left unattended for an extended period of time, equipment
operation must be checked periodically. If this is not pos-
sible, the water supply to the house should be shut off and
the pipes should be drained. This will prevent problems
associated with a NO HEAT condition (frozen pipes, etc.)
FIGURE 1
WARNING
Before attempting to perform any service or maintenance,
turn the electrical power to unit OFF at the disconnect
switch.
NOTICE
Any additions, changes, or conversions required in order
for the appliance to satisfactorily meet the application
needs must be made by a licensed professional installer
(or equivalent) using factory-specied and approved
parts.
