Start-Up & Operation Information
WARNING
If you do not follow these instructions exactly, a re or
explosion may result causing property damage, personal
injury or death.
BEFORE PLACING THE UNIT INTO OPERATION, smell
all around the appliance area for gas. Be sure to smell
next to the oor because some gas is heavier than air and
will settle on the oor.
The gas valve on the SLP98UH is equipped with a gas
control switch. Use only your hand to move the control
switch. Never use tools. If the switch will not move by
hand, do not try to repair it. Call a licensed professional
service technician (or equivalent). Force or attempted re-
pair may result in a re or explosion.
Placing the SLP9UH furnace into operation:
SLP98UH units are equipped with a SureLight® ign tion
system. Do not attempt to manually light burners on this
furnace. Each time the thermostat calls for heat, the burn-
ers will automatically light. The ignitor does not get hot
when there is no call for heat on units with SureLight®
ignition system.
Operating the Gas Valve (Figure 2)
1 - STOP! Read the safety information at the beginning
of this section.
2 - Set the thermostat to the lowest setting.
3 - Turn off all electrical power to the unit.
4 - This furnace is equipped with an ignition device
which automatically lights the burners. Do not try to
light the burners by hand.
5 - Remove the outer access panel.
6 - Move the gas valve switch to the OFF position
gure 2.
7 - Wait ve minutes to clear out any gas. If you then
smell gas, STOP! Immediately call your gas supplier
from neighbor’s phone. Follow the gas supplier’s
instructions. If you do not smell gas go to next step.
VARIABLE CAPACITY GAS VALVE
GAS VALVE SHOWN IN ON POSITION
GAS VALVE
SWITCH
FIGURE 2
8 - Move gas valve switch to ON position. See gure 2.
9 - Replace the outer access panel.
10 - Tur n on all electrical power to to the unit
11 - Se t the thermostat to desired setting.
NOTE - When unit is initially started, steps 1 through
11 may need to be repeated to purge air from gas line.
12 - If the appliance will not operate, follow the section
“Turning Off Gas to the Unit” and call your service
technician or gas supplier.
Turning Off Gas to the Unit
WARNING
If overheating occurs or if gas supply fails to shut off,
shut off the manual gas valve to the furnace before
shutting off electrical supply.
1 - Set the th ermostat to the lowest setting.
2 - Turn off all electrical power to the unit if service is to
be performed.
3 - Remove the outer access panel.
4 - Move the gas valve switch to the OFF position.
5 - Replace the outer access panel.
CAUTION
Do not set thermostat below 60F (16C) in heating mode.
Setting below 60F (16C) reduces the number of heating
cycles. Damage to the unit may occur that is not covered
by the warranty.
Filters
All SLP98UH lters are installed external to the unit. Filters
should be inspected monthly. Clean or replace the lter(s)
when necessary to ensure proper furnace operation. A l-
ter must be in place when the unit is operating. See
table 1 for recommended lter sizes.
NOTE - Use replacement lters that are similar in size
and efciency ratings to those originally provided by the
installing contractor. Use of replacement lters with higher
ltration ratings may restrict air ow to the furnace. This
may result in reduced unit efciency, as well as premature
blower motor failure.
The lter access panel must also be in place and properly
secured during unit operation.
TABLE 1
Furnace
Cabinet Width
Filter Size
Side Return Bottom Return
17-1/2” 16 x 25 x 1 (1) 16 x 25 x 1 (1)
21-1/2” 16 x 25 x 1 (1) 16 x 25 x 1 (1)
24-1/2” 16 x 15 x 1 (1) 16 x 25 x 1 (1)
