NOTES: For Temperatures and Capacities not shown in tables, see bulletin − Cooling Unit Rating Table Correction Factor Data in Miscellaneous Engineering Data section.
RATINGS 10 TON (DUAL CIRCUIT)
TS 6 to 20 Ton R−410A Air Conditioners / Page 22
AIR HANDLERS
COOLING CAPACITY − TSA120S4D (FIRST STAGE) with [TAA120S4D]
Entering
Wet Bulb
Tempera-
ture
Total
Air
Volume
Outdoor Air Temperature Entering Outdoor Coil
65_F (18_C) 75_F (24_C) 85_F (29_C) 95_F (35_C)
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
cfm L/s kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
63_F
(17_C)
3200 1510 61.7 18.1 2.72 .65 .78 .94 59.4 17.4 3.08 .66 .80 .96 56.8 16.6 3.49 .67 .82 .99 54.2 15.9 3.95 .68 .85 1.00
4000 1890 64.7 19.0 2.76 .69 .87 1.00 62.1 18.2 3.11 .70 .89 1.00 59.4 17.4 3.52 .72 .92 1.00 56.6 16.6 3.97 .74 .95 1.00
4800 2265 66.9 19.6 2.79 .74 .95 1.00 64.3 18.8 3.14 .76 .97 1.00 61.6 18.1 3.55 .78 .99 1.00 58.7 17.2 4.01 .81 1.00 1.00
67_F
(19_C)
3200 1510 65.3 19.1 2.77 .52 .62 .74 62.8 18.4 3.12 .52 .63 .75 60.2 17.6 3.53 .53 .64 .78 57.5 16.9 3.99 .54 .66 .80
4000 1890 68.5 20.1 2.80 .54 .67 .82 65.7 19.3 3.16 .55 .68 .84 62.8 18.4 3.56 .55 .69 .87 59.9 17.6 4.03 .57 .71 .91
4800 2265 70.6 20.7 2.83 .56 .71 .91 67.8 19.9 3.19 .57 .73 .93 64.8 19.0 3.59 .59 .76 .96 61.6 18.1 4.04 .59 .78 .99
71_F
(22_C)
3200 1510 68.9 20.2 2.81 .40 .50 .60 66.3 19.4 3.17 .40 .51 .61 63.5 18.6 3.57 .40 .51 .62 60.7 17.8 4.04 .40 .52 .64
4000 1890 72.2 21.2 2.84 .41 .53 .65 69.3 20.3 3.21 .41 .54 .66 66.2 19.4 3.61 .41 .54 .67 63.2 18.5 4.07 .41 .56 .69
4800 2265 74.4 21.8 2.87 .41 .55 .69 71.5 21.0 3.24 .42 .56 .71 68.3 20.0 3.64 .42 .58 .73 65.0 19.0 4.10 .43 .59 .75
COOLING CAPACITY − TSA120S4D (SECOND STAGE) with [TAA120S4D]
Entering
Wet Bulb
Tempera-
ture
Total
Air
Volume
Outdoor Air Temperature Entering Outdoor Coil
85_F (29_C) 95_F (35_C) 105_F (41_C) 115_F (46_C)
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
cfm L/s kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
63_F
(17_C)
3200 1510 113.6 33.3 6.99 .67 .82 .99 108.2 31.7 7.91 .68 .85 1.00 102.5 30.0 8.99 .69 .88 1.00 96.4 28.3 10.22 .72 .92 1.00
4000 1890 118.9 34.8 7.04 .72 .92 1.00 113.1 33.1 7.95 .74 .95 1.00 107.3 31.4 9.03 .77 .98 1.00 100.8 29.5 10.28 .80 1.00 1.00
4800 2265 123.1 36.1 7.10 .78 .99 1.00 117.3 34.4 8.02 .81 1.00 1.00 112.0 32.8 9.11 .84 1.00 1.00 105.6 30.9 10.37 .88 1.00 1.00
67_F
(19_C)
3200 1510 120.5 35.3 7.06 .53 .64 .78 114.9 33.7 7.99 .54 .66 .80 108.8 31.9 9.06 .54 .68 .84 102.4 30.0 10.30 .56 .70 .87
4000 1890 125.6 36.8 7.12 .56 .69 .87 119.7 35.1 8.06 .57 .71 .91 113.3 33.2 9.12 .58 .74 .94 105.9 31.0 10.34 .59 .77 .98
4800 2265 129.6 38.0 7.18 .59 .76 .96 123.2 36.1 8.09 .60 .78 .99 116.3 34.1 9.16 .61 .81 1.00 108.8 31.9 10.38 .63 .85 1.00
71_F
(22_C)
3200 1510 127.0 37.2 7.15 .40 .51 .62 121.3 35.5 8.08 .40 .52 .64 114.8 33.6 9.15 .41 .53 .65 108.0 31.7 10.39 .41 .54 .67
4000 1890 132.4 38.8 7.22 .41 .54 .67 126.5 37.1 8.15 .41 .56 .69 119.4 35.0 9.22 .42 .57 .71 112.1 32.9 10.45 .43 .58 .75
4800 2265 136.5 40.0 7.29 .42 .58 .73 129.9 38.1 8.21 .43 .59 .75 122.7 36.0 9.27 .43 .60 .78 115.1 33.7 10.52 .44 .63 .83
UP−FLOW INDOOR COIL
COOLING CAPACITY − TSA120S4D (FIRST STAGE) with [(2) CX34−60D−6F]
Entering
Wet Bulb
Tempera-
ture
Total
Air
Volume
Outdoor Air Temperature Entering Outdoor Coil
65_F (18_C) 75_F (24_C) 85_F (29_C) 95_F (35_C)
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
cfm L/s kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
63_F
(17_C)
3200 1510 59.2 17.3 2.70 .64 .77 .91 57.1 16.7 3.06 .65 .78 .93 54.9 16.1 3.47 .66 .80 .96 52.5 15.4 3.93 .67 .82 .99
4000 1890 62.3 18.3 2.73 .67 .83 .99 60.0 17.6 3.09 .68 .85 1.00 57.5 16.9 3.50 .70 .88 1.00 54.9 16.1 3.96 .72 .91 1.00
4800 2265 64.7 19.0 2.76 .71 .89 1.00 62.2 18.2 3.12 .73 .92 1.00 59.6 17.5 3.52 .75 .95 1.00 56.8 16.6 3.98 .77 .99 1.00
67_F
(19_C)
3200 1510 62.7 18.4 2.74 .52 .62 .73 60.5 17.7 3.10 .52 .63 .74 58.1 17.0 3.50 .53 .63 .76 55.5 16.3 3.96 .53 .65 .78
4000 1890 65.7 19.3 2.77 .53 .65 .79 63.4 18.6 3.13 .54 .66 .81 60.8 17.8 3.53 .55 .67 .84 58.0 17.0 4.00 .56 .69 .86
4800 2265 68.1 20.0 2.80 .55 .69 .85 65.4 19.2 3.16 .56 .69 .88 62.5 18.3 3.56 .57 .72 .91 59.8 17.5 4.02 .58 .74 .95
71_F
(22_C)
3200 1510 66.2 19.4 2.78 .40 .50 .59 63.8 18.7 3.14 .40 .50 .60 61.4 18.0 3.55 .40 .51 .61 58.6 17.2 4.01 .41 .52 .62
4000 1890 69.5 20.4 2.81 .41 .52 .63 67.0 19.6 3.18 .41 .53 .64 64.2 18.8 3.58 .41 .53 .66 61.2 17.9 4.04 .42 .54 .67
4800 2265 71.9 21.1 2.84 .42 .54 .67 69.2 20.3 3.21 .42 .55 .67 66.2 19.4 3.61 .42 .56 .70 63.1 18.5 4.08 .43 .57 .72
COOLING CAPACITY − TSA120S4D (SECOND STAGE) with [(2) CX34−60D−6F]
Entering
Wet Bulb
Tempera-
ture
Total
Air
Volume
Outdoor Air Temperature Entering Outdoor Coil
85_F (29_C) 95_F (35_C) 105_F (41_C) 115_F (46_C)
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
cfm L/s kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
63_F
(17_C)
3200 1510 109.8 32.2 6.94 .66 .80 .96 104.9 30.7 7.86 .67 .82 .99 99.5 29.2 8.94 .68 .85 1.00 93.8 27.5 10.20 .70 .89 1.00
4000 1890 115.1 33.7 7.00 .70 .88 1.00 109.8 32.2 7.93 .72 .91 1.00 104.1 30.5 8.99 .74 .94 1.00 98.1 28.8 10.24 .77 .98 1.00
4800 2265 119.2 34.9 7.04 .75 .95 1.00 113.6 33.3 7.97 .77 .99 1.00 107.6 31.5 9.05 .80 1.00 1.00 101.9 29.9 10.30 .84 1.00 1.00
67_F
(19_C)
3200 1510 116.1 34.0 7.01 .53 .63 .76 111.0 32.5 7.93 .53 .65 .78 105.5 30.9 9.02 .54 .66 .81 99.3 29.1 10.28 .55 .68 .85
4000 1890 121.5 35.6 7.06 .55 .67 .84 115.9 34.0 8.01 .56 .69 .86 109.8 32.2 9.08 .57 .71 .90 103.2 30.2 10.33 .58 .74 .94
4800 2265 125.0 36.6 7.13 .57 .72 .91 119.5 35.0 8.05 .58 .75 .95 112.9 33.1 9.12 .59 .77 .98 106.3 31.2 10.35 .61 .81 1.00
71_F
(22_C)
3200 1510 122.7 36.0 7.10 .40 .51 .61 117.3 34.4 8.02 .41 .52 .62 111.3 32.6 9.07 .41 .52 .64 105.0 30.8 10.35 .41 .54 .66
4000 1890 128.4 37.6 7.16 .41 .53 .66 122.3 35.8 8.08 .42 .54 .67 116.1 34.0 9.16 .42 .56 .69 109.1 32.0 10.40 .43 .57 .72
4800 2265 132.4 38.8 7.23 .42 .56 .70 126.2 37.0 8.16 .43 .57 .72 119.5 35.0 9.21 .43 .59 .75 112.1 32.9 10.43 .44 .60 .78
