NOTES: For Temperatures and Capacities not shown in tables, see bulletin − Cooling Unit Rating Table Correction Factor Data in Miscellaneous Engineering Data section.
RATINGS 10 TON (DUAL CIRCUIT)
TS 6 to 20 Ton R−410A Air Conditioners / Page 23
UP−FLOW INDOOR COIL
COOLING CAPACITY − TSA120S4D (FIRST STAGE) with [(2) CX34−62D−6F]
Entering
Wet Bulb
Tempera-
ture
Total
Air
Volume
Outdoor Air Temperature Entering Outdoor Coil
65_F (18_C) 75_F (24_C) 85_F (29_C) 95_F (35_C)
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
cfm L/s kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
63_F
(17_C)
3200 1510 59.9 17.6 2.71 .64 .76 .91 57.8 16.9 3.07 .65 .78 .93 55.5 16.3 3.47 .66 .80 .96 53.0 15.5 3.93 .67 .82 .99
4000 1890 63.0 18.5 2.74 .67 .83 .99 60.8 17.8 3.10 .68 .85 1.00 58.2 17.1 3.51 .70 .88 1.00 55.5 16.3 3.96 .72 .91 1.00
4800 2265 65.5 19.2 2.77 .71 .90 1.00 63.0 18.5 3.13 .73 .92 1.00 60.4 17.7 3.53 .75 .95 1.00 57.5 16.9 3.99 .77 .98 1.00
67_F
(19_C)
3200 1510 63.2 18.5 2.74 .52 .62 .72 61.0 17.9 3.10 .52 .63 .74 58.5 17.1 3.50 .53 .63 .76 55.9 16.4 3.97 .53 .65 .78
4000 1890 66.5 19.5 2.78 .53 .65 .79 63.8 18.7 3.13 .54 .66 .81 61.2 17.9 3.54 .55 .67 .83 58.5 17.1 4.01 .56 .69 .87
4800 2265 68.9 20.2 2.81 .55 .68 .85 66.2 19.4 3.17 .56 .70 .88 63.4 18.6 3.57 .57 .72 .91 60.4 17.7 4.03 .58 .75 .95
71_F
(22_C)
3200 1510 66.8 19.6 2.78 .40 .50 .59 64.4 18.9 3.14 .40 .50 .60 61.9 18.1 3.56 .40 .51 .61 59.1 17.3 4.02 .41 .52 .63
4000 1890 70.2 20.6 2.82 .41 .52 .63 67.6 19.8 3.18 .41 .53 .64 64.8 19.0 3.58 .41 .53 .66 61.7 18.1 4.05 .42 .54 .67
4800 2265 72.7 21.3 2.85 .42 .54 .66 69.9 20.5 3.22 .42 .55 .68 66.9 19.6 3.62 .42 .56 .69 63.7 18.7 4.08 .43 .57 .72
COOLING CAPACITY − TSA120S4D (SECOND STAGE) with [(2) CX34−62D−6F]
Entering
Wet Bulb
Tempera-
ture
Total
Air
Volume
Outdoor Air Temperature Entering Outdoor Coil
85_F (29_C) 95_F (35_C) 105_F (41_C) 115_F (46_C)
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
cfm L/s kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
63_F
(17_C)
3200 1510 111.0 32.5 6.94 .66 .80 .96 105.9 31.0 7.87 .67 .82 .99 100.6 29.5 8.95 .68 .85 1.00 94.8 27.8 10.22 .70 .89 1.00
4000 1890 116.3 34.1 7.02 .70 .88 1.00 111.1 32.6 7.93 .72 .91 1.00 105.4 30.9 9.01 .74 .94 1.00 99.1 29.0 10.28 .77 .98 1.00
4800 2265 120.7 35.4 7.06 .75 .95 1.00 115.0 33.7 7.98 .77 .98 1.00 108.9 31.9 9.07 .80 1.00 1.00 103.0 30.2 10.31 .83 1.00 1.00
67_F
(19_C)
3200 1510 116.9 34.3 7.01 .53 .63 .76 111.7 32.7 7.94 .53 .65 .78 106.0 31.1 9.02 .54 .66 .81 99.8 29.2 10.27 .55 .68 .84
4000 1890 122.4 35.9 7.09 .55 .67 .83 116.9 34.3 8.02 .56 .69 .87 110.9 32.5 9.10 .57 .71 .90 104.3 30.6 10.34 .58 .74 .94
4800 2265 126.8 37.2 7.15 .57 .72 .91 120.8 35.4 8.07 .58 .75 .95 114.5 33.6 9.14 .59 .77 .98 107.4 31.5 10.38 .61 .81 1.00
71_F
(22_C)
3200 1510 123.7 36.3 7.12 .40 .51 .61 118.1 34.6 8.04 .41 .52 .63 112.1 32.9 9.11 .41 .52 .64 105.7 31.0 10.35 .41 .53 .66
4000 1890 129.5 38.0 7.17 .41 .53 .66 123.4 36.2 8.10 .42 .54 .67 117.2 34.3 9.19 .42 .56 .68 110.1 32.3 10.43 .43 .57 .71
4800 2265 133.8 39.2 7.24 .42 .56 .69 127.4 37.3 8.17 .43 .57 .72 120.5 35.3 9.24 .43 .59 .75 113.0 33.1 10.45 .44 .60 .78
DOWN−FLOW INDOOR COILS
COOLING CAPACITY − TSA120S4D (FIRST STAGE) with [(2) CR33−50/60C−2F]
Entering
Wet Bulb
Tempera-
ture
Total
Air
Volume
Outdoor Air Temperature Entering Outdoor Coil
65_F (18_C) 75_F (24_C) 85_F (29_C) 95_F (35_C)
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
cfm L/s kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
63_F
(17_C)
3200 1510 58.5 17.1 2.70 .65 .77 .92 56.4 16.5 3.06 .66 .79 .95 54.2 15.9 3.46 .66 .81 .97 51.6 15.1 3.91 .68 .83 .99
4000 1890 61.3 18.0 2.72 .68 .84 .99 59.0 17.3 3.08 .69 .87 1.00 56.5 16.6 3.49 .70 .89 1.00 53.9 15.8 3.95 .72 .92 1.00
4800 2265 63.3 18.6 2.74 .72 .91 1.00 60.9 17.8 3.11 .74 .94 1.00 58.2 17.1 3.50 .75 .96 1.00 55.5 16.3 3.97 .78 .98 1.00
67_F
(19_C)
3200 1510 61.8 18.1 2.73 .52 .62 .73 59.5 17.4 3.09 .52 .63 .75 57.2 16.8 3.49 .53 .64 .77 54.6 16.0 3.96 .54 .65 .79
4000 1890 64.8 19.0 2.76 .54 .66 .80 62.3 18.3 3.12 .55 .67 .82 59.7 17.5 3.52 .56 .68 .85 57.0 16.7 3.98 .56 .70 .88
4800 2265 67.0 19.6 2.79 .56 .69 .87 64.3 18.8 3.14 .57 .71 .90 61.6 18.1 3.55 .58 .73 .92 58.7 17.2 4.01 .59 .75 .96
71_F
(22_C)
3200 1510 65.0 19.0 2.76 .40 .50 .60 62.6 18.3 3.12 .40 .51 .61 60.1 17.6 3.52 .40 .52 .62 57.5 16.9 3.99 .40 .52 .63
4000 1890 68.1 20.0 2.80 .41 .53 .64 65.6 19.2 3.16 .41 .54 .65 62.9 18.4 3.56 .41 .54 .66 59.9 17.6 4.02 .42 .55 .68
4800 2265 70.4 20.6 2.82 .42 .55 .67 67.7 19.8 3.19 .42 .56 .69 64.8 19.0 3.59 .43 .57 .70 61.8 18.1 4.05 .43 .58 .73
COOLING CAPACITY − TSA120S4D (SECOND STAGE) with [(2) CR33−50/60C−2F]
Entering
Wet Bulb
Tempera-
ture
Total
Air
Volume
Outdoor Air Temperature Entering Outdoor Coil
85_F (29_C) 95_F (35_C) 105_F (41_C) 115_F (46_C)
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
cfm L/s kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
63_F
(17_C)
3200 1510 108.3 31.7 6.93 .66 .81 .97 103.2 30.2 7.84 .68 .84 .99 98.0 28.7 8.93 .69 .86 1.00 92.2 27.0 10.17 .71 .90 1.00
4000 1890 113.1 33.1 6.98 .70 .89 1.00 107.7 31.6 7.90 .72 .92 1.00 102.1 29.9 8.99 .75 .95 1.00 95.9 28.1 10.23 .78 .98 1.00
4800 2265 116.4 34.1 7.01 .76 .96 1.00 111.0 32.5 7.95 .78 .98 1.00 105.6 30.9 9.02 .81 1.00 1.00 99.9 29.3 10.26 .84 1.00 1.00
67_F
(19_C)
3200 1510 114.4 33.5 6.99 .53 .64 .77 109.2 32.0 7.92 .54 .65 .79 103.7 30.4 8.97 .55 .67 .82 97.6 28.6 10.25 .56 .69 .86
4000 1890 119.4 35.0 7.04 .56 .68 .85 113.9 33.4 7.97 .56 .70 .88 108.0 31.7 9.06 .58 .72 .91 101.5 29.7 10.29 .59 .75 .95
4800 2265 123.2 36.1 7.10 .58 .73 .92 117.4 34.4 8.02 .59 .75 .96 111.0 32.5 9.10 .60 .78 .98 104.1 30.5 10.31 .62 .82 1.00
71_F
(22_C)
3200 1510 120.2 35.2 7.06 .40 .52 .62 115.0 33.7 7.99 .40 .52 .63 109.2 32.0 9.08 .41 .53 .65 102.8 30.1 10.29 .41 .54 .67
4000 1890 125.7 36.8 7.13 .41 .54 .66 119.8 35.1 8.04 .42 .55 .68 113.7 33.3 9.13 .42 .56 .69 107.0 31.4 10.36 .43 .58 .72
4800 2265 129.6 38.0 7.19 .43 .57 .70 123.5 36.2 8.11 .43 .58 .73 116.9 34.3 9.17 .43 .59 .75 109.8 32.2 10.42 .44 .61 .79
