NOTES: For Temperatures and Capacities not shown in tables, see bulletin − Cooling Unit Rating Table Correction Factor Data in Miscellaneous Engineering Data section.
RATINGS 10 TON (DUAL CIRCUIT)
TS 6 to 20 Ton R−410A Air Conditioners / Page 24
HORIZONTAL INDOOR COILS
COOLING CAPACITY − TSA120S4D (FIRST STAGE) with [(2) CH33−62D−2F]
Entering
Wet Bulb
Temperat
ure
Total
Air
Volume
Outdoor Air Temperature Entering Outdoor Coil
65_F (18_C) 75_F (24_C) 85_F (29_C) 95_F (35_C)
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
cfm L/s kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
63_F
(17_C)
3200 1510 59.2 17.3 2.70 .64 .76 .89 57.1 16.7 3.06 .64 .77 .92 54.9 16.1 3.47 .65 .79 .94 52.5 15.4 3.93 .66 .81 .97
4000 1890 62.4 18.3 2.73 .67 .82 .98 60.0 17.6 3.09 .68 .84 1.00 57.6 16.9 3.49 .69 .86 1.00 55.0 16.1 3.96 .71 .89 1.00
4800 2265 64.8 19.0 2.76 .70 .88 1.00 62.3 18.3 3.12 .72 .90 1.00 59.6 17.5 3.52 .73 .93 1.00 56.8 16.6 3.98 .76 .96 1.00
67_F
(19_C)
3200 1510 62.4 18.3 2.73 .51 .61 .72 60.1 17.6 3.09 .52 .62 .73 57.7 16.9 3.49 .52 .63 .75 55.2 16.2 3.95 .53 .64 .77
4000 1890 65.7 19.3 2.77 .53 .64 .78 63.1 18.5 3.13 .54 .66 .80 60.7 17.8 3.54 .54 .67 .82 57.9 17.0 3.99 .55 .68 .85
4800 2265 68.3 20.0 2.80 .55 .68 .84 65.6 19.2 3.16 .56 .69 .86 62.8 18.4 3.56 .56 .71 .89 59.9 17.6 4.02 .58 .73 .92
71_F
(22_C)
3200 1510 65.7 19.3 2.77 .40 .50 .59 63.5 18.6 3.13 .40 .50 .60 61.0 17.9 3.54 .40 .51 .61 58.3 17.1 4.00 .41 .51 .62
4000 1890 69.3 20.3 2.81 .41 .52 .62 66.7 19.5 3.17 .41 .52 .63 64.0 18.8 3.58 .41 .53 .65 60.9 17.8 4.04 .42 .54 .66
4800 2265 71.8 21.0 2.84 .42 .54 .66 69.1 20.3 3.20 .42 .54 .67 66.1 19.4 3.61 .42 .55 .68 63.0 18.5 4.07 .43 .56 .70
COOLING CAPACITY − TSA120S4D (SECOND STAGE) with [(2) CH33−62D−2F]
Entering
Wet Bulb
Tempera-
ture
Total
Air
Volume
Outdoor Air Temperature Entering Outdoor Coil
85_F (29_C) 95_F (35_C) 105_F (41_C) 115_F (46_C)
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
cfm L/s kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
63_F
(17_C)
3200 1510 109.7 32.1 6.94 .65 .79 .94 104.9 30.7 7.86 .66 .81 .97 99.5 29.2 8.94 .68 .84 1.00 93.8 27.5 10.20 .69 .87 1.00
4000 1890 115.2 33.8 6.99 .69 .86 1.00 110.0 32.2 7.93 .71 .89 1.00 104.1 30.5 9.01 .73 .92 1.00 97.9 28.7 10.24 .76 .96 1.00
4800 2265 119.1 34.9 7.04 .73 .93 1.00 113.6 33.3 7.96 .76 .96 1.00 107.6 31.5 9.03 .78 .99 1.00 101.2 29.7 10.27 .82 1.00 1.00
67_F
(19_C)
3200 1510 115.4 33.8 6.99 .52 .63 .75 110.3 32.3 7.91 .53 .64 .77 104.9 30.7 9.00 .54 .65 .80 98.6 28.9 10.27 .55 .67 .83
4000 1890 121.4 35.6 7.08 .54 .67 .82 115.8 33.9 8.00 .55 .68 .85 110.0 32.2 9.08 .56 .70 .88 103.3 30.3 10.34 .57 .73 .92
4800 2265 125.6 36.8 7.13 .56 .71 .89 119.7 35.1 8.05 .58 .73 .92 113.4 33.2 9.12 .59 .76 .96 106.5 31.2 10.36 .60 .79 1.00
71_F
(22_C)
3200 1510 121.9 35.7 7.08 .40 .51 .61 116.6 34.2 8.00 .41 .51 .62 110.7 32.4 9.09 .41 .52 .63 104.4 30.6 10.34 .41 .53 .65
4000 1890 127.9 37.5 7.16 .41 .53 .65 121.8 35.7 8.08 .42 .54 .66 115.7 33.9 9.17 .42 .55 .68 108.9 31.9 10.42 .43 .56 .70
4800 2265 132.2 38.7 7.23 .42 .55 .68 126.0 36.9 8.15 .43 .56 .70 119.4 35.0 9.21 .43 .58 .73 112.2 32.9 10.47 .44 .59 .76
