TS − 3 to 5 Ton R−410A Air Conditioners / Page 12
ARI RATINGS
1
ARI Standard 210/240 Ratings
Expansion
Cooling Capacity Efficiency
Total Unit
Indoor Unit Model No.
Expansion
Device
Btuh SEER EER
Total
Unit
Watts
D
ev
i
ce
TSA042S4 3.5 TON
Up-Flow Indoor Coils + Furnace Continued from Previous Page
41,000 14.00 11.50 3510 CX34−49C−6F
4
G60UHV−60C−110
2
39L72
41,000 14.00 11.50 3525 CX34−49C−6F
4
G71MPP−60C−110
2
39L72
41,000 14.00 11.50 3525 CX34−49C−6F
4
G61MPV−60C−110
2
39L72
41,000 14.00 11.50 3530 CX34−50/60C−6F
4
G60UHV−60C−110
2
39L72
41,000 14.00 11.50 3535 CX34−43C−6F
4
G60UHV−60C−110 Factory TXV
41,000 14.00 11.50 3545 CX34−50/60C−6F
4
G71MPP−60C−110
2
39L72
41,000 14.00 11.50 3545 CX34−50/60C−6F
4
G61MPV−60C−110
2
39L72
41,000 14.00 11.50 3550 CX34−43B−6F
4
G60UHV−36B−090 Factory TXV
41,000 14.00 11.50 3550 CX34−43C−6F
4
G71MPP−60C−110 Factory TXV
41,000 14.00 11.50 3550 CX34−43C−6F
4
G61MPV−60C−110 Factory TXV
41,500 13.50 11.50 3595 CX34−43C−6F
4
G71MPP−60C−090 Factory TXV
41,500 13.50 11.50 3595 CX34−43C−6F
4
G61MPV−60C−090 Factory TXV
Down-Flow Indoor Coils Down−Flow Coils
40,000 13.00 10.80 3700
3
CR33−50/60C−F
2
39L72
40,000 13.00 10.80 3700
3
CR33−60D−F
2
39L72
Down-Flow Indoor Coils + Furnace Down−Flow Coils + Furnace
40,500 14.00 11.50 3475 CR33−50/60C−F
4
G60DFV−60C−090
2
39L72
40,500 14.00 11.50 3520 CR33−50/60C−F
4
G71MPP−60C−110
2
39L72
40,500 14.00 11.50 3520 CR33−50/60C−F
4
G61MPV−60C−110
2
39L72
41,000 14.00 11.50 3495 CR33−60D−F
4
G60DFV−60D−135
2
39L72
41,000 14.00 11.50 3495 CR33−60D−F
4
G71MPP−60D−135
2
39L72
41,000 14.00 11.50 3495 CR33−60D−F
4
G61MPV−60D−135
2
39L72
41,000 14.00 11.50 3515 CR33−50/60C−F
4
G60DFV−60C−110
2
39L72
41,000 14.00 11.50 3565 CR33−50/60C−F
4
G71MPP−60C−090
2
39L72
41,000 14.00 11.50 3565 CR33−50/60C−F
4
G61MPV−60C−090
2
39L72
Horizontal Indoor Coils Horizontal Coils
39,500 13.00 10.70 3690
3
CH23−65
2
39L72
40,000 13.00 10.80 3700
3
CH33−48C−2F
2
39L72
41,000 13.00 11.00 3725
3
CH33−43B/C−2F
2
39L72
41,000 13.00 11.00 3725
3
CH33−49C−2F
2
39L72
41,000 13.00 11.00 3715
3
CH33−50/60C−2F
2
39L72
Horizontal Indoor Coils + Furnace Horizontal Coils + Furnace
40,500 13.50 11.00 3555 CH23−65
4
G60UHV−60C−090
2
39L72
40,500 13.50 11.00 3595 CH23−65
4
G71MPP−60C−090
2
39L72
40,500 13.50 11.00 3595 CH23−65
4
G61MPV−60C−090
2
39L72
41,000 13.50 11.00 3725 CH33−43C−2F
4
G71MPP−36C−090
2
39L72
41,000 13.50 11.00 3725 CH33−43C−2F
4
G61MPV−36C−090
2
39L72
41,000 13.50 11.50 3565 CH33−43C−2F
4
G71MPP−60C−090
2
39L72
41,000 13.50 11.50 3565 CH33−43C−2F
4
G61MPV−60C−090
2
39L72
41,000 13.50 11.00 3725 CH33−43C−2F
4
G61MPV−60C−111
2
39L72
Horizontal Indoor Coils + Furnace Continued on Next Page
1
Certified in accordance with USE certification program which is based on ARI Standard 210/240; 95_F outdoor air temperature, 80_F db/67_F wb entering evaporator air
with 25 ft. of connecting refrigerant lines.
2
Factory installed RFC or expansion valve on indoor unit MUST be replaced with expansion valve kit (ordered separately) shown.
3
Blower must be capable of time−off blower delay. Indoor Blower Off Delay Relay (58M81) is recommended for field installation.
4
Blower control must be set for a time−off blower delay.
