Lennox TSA048S4 User Manual

TS − 3 to 5 Ton R−410A Air Conditioners / Page 13
ARI RATINGS
1
ARI Standard 210/240 Ratings
Ei
Cooling Capacity Efficiency
Total Unit
Indoor Unit Model No.
Expansion
Device
Btuh SEER EER
Total
Unit
Watts
D
ev
i
ce
TSA042S4 3.5 TON
Horizontal Indoor Coils + Furnace Horizontal Coils + Furnace
41,000 13.50 11.00 3605 CH33−48C−2F
4
G71MPP−60C−090
2
39L72
41,000 13.50 11.00 3605 CH33−48C−2F
4
G61MPV−60C−090
2
39L72
41,000 13.50 11.50 3565 CH33−48C−2F
4
G71MPP−60C−110
2
39L72
41,000 13.50 11.50 3565 CH33−48C−2F
4
G61MPV−60C−110
2
39L72
41,000 14.00 11.50 3565 CH33−43C−2F
4
G60UHV−60C−090
2
39L72
41,000 14.00 11.50 3565 CH33−43C−2F
4
G60UHV−60C−110
2
39L72
41,000 14.00 11.50 3565 CH33−43C−2F
4
G71MPP−60C−110
2
39L72
41,000 14.00 11.50 3565 CH33−43C−2F
4
G61MPV−60C−110
2
39L72
41,500 13.00 10.90 3805 CH33−43B−2F
4
G61MPV−36B−045
2
39L72
41,500 13.00 11.00 3775 CH33−43B−2F
4
G71MPP−36B−070
2
39L72
41,500 13.00 11.00 3775 CH33−43B−2F
4
G61MPV−36B−070
2
39L72
41,500 13.00 11.00 3775 CH33−43B−2F
4
G61MPV−36B−071
2
39L72
41,500 13.50 11.50 3610 CH33−43B−2F
4
G60UHV−36B−090
2
39L72
41,500 13.50 11.00 3775 CH33−43C−2F
4
G61MPV−60C−091
2
39L72
41,500 13.50 11.00 3775 CH33−49C−2F
4
G71MPP−36C−090
2
39L72
41,500 13.50 11.00 3775 CH33−49C−2F
4
G61MPV−36C−090
2
39L72
41,500 13.50 11.50 3610 CH33−49C−2F
4
G71MPP−60C−090
2
39L72
41,500 13.50 11.50 3610 CH33−49C−2F
4
G61MPV−60C−090
2
39L72
41,500 13.50 11.00 3775 CH33−49C−2F
4
G61MPV−60C−091
2
39L72
41,500 13.50 11.50 3575 CH33−50/60C−2F
4
G71MPP−60C−110
2
39L72
41,500 13.50 11.50 3575 CH33−50/60C−2F
4
G61MPV−60C−110
2
39L72
41,500 13.50 11.50 3615 CH33−50/60C−2F
4
G71MPP−60C−090
2
39L72
41,500 13.50 11.50 3615 CH33−50/60C−2F
4
G61MPV−60C−090
2
39L72
41,500 14.00 11.50 3610 CH33−49C−2F
4
G60UHV−60C−090
2
39L72
41,500 14.00 11.50 3610 CH33−49C−2F
4
G60UHV−60C−110
2
39L72
41,500 14.00 11.50 3610 CH33−49C−2F
4
G61MPV−60C−110
2
39L72
41,500 14.00 11.50 3610 CH33−49C−2F
4
G71MPP−60C−110
2
39L72
41,500 14.00 11.50 3610 CH33−49C−2F
4
G61MPV−60C−111
2
39L72
41,500 14.00 11.50 3575 CH33−50/60C−2F
4
G60UHV−60C−090
2
39L72
Air Handlers Air Handlers
38,500 12.50 10.50 3675
3
CB29M−46 (Multi−Position)
2
39L72
39,500 13.00 10.90 3605
3
CBX32M−042 (Multi−Position)
2
39L72
39,500 13.00 10.90 3620
3
CBX32M−036 (Multi−Position)
2
39L72
40,000 13.00 11.00 3635 CBX26UH−042 (Up−Flow/Horizontal) Factory TXV
41,000 13.00 11.00 3715
3
CBX32M−048 (Multi−Position)
2
39L72
41,000 14.00 11.50 3565
4
CBX27UH−048 (Up−Flow / Horizontal)
2
39L72
41,500 14.00 11.50 3590
4
CBX32MV−048 (Multi−Position)
2
39L72
41,500 14.00 11.50 3610
4
CBX27UH−042 (Up−Flow / Horizontal) Factory TXV
1
Certified in accordance with USE certification program which is based on ARI Standard 210/240; 95_F outdoor air temperature, 80_F db/67_F wb entering evaporator air
with 25 ft. of connecting refrigerant lines.
2
Factory installed RFC or expansion valve on indoor unit MUST be replaced with expansion valve kit (ordered separately) shown.
3
Blower must be capable of time−off blower delay. Indoor Blower Off Delay Relay (58M81) is recommended for field installation.
4
Blower control must be set for a time−off blower delay.
