Lennox TSA048S4 User Manual

TS − 3 to 5 Ton R−410A Air Conditioners / Page 14
ARI RATINGS
1
ARI Standard 210/240 Ratings
Ei
Cooling Capacity Efficiency
Total Unit
Indoor Unit Model No.
Expansion
Device
Btuh SEER EER
Total
Unit
Watts
D
ev
i
ce
tsa048s4 4 TON
Up-Flow Indoor Coils Up−Flow Coils
47,000 13.00 11.00 4255
3
CX34−38A/B−6F
2
91M02
47,000 13.00 11.00 4255
3, 5
CX34−50/60C−6F Factory TXV
47,500 13.00 11.00 4260
3
CX34−43B/C−6F
2
91M02
48,000 13.50 11.00 4265
3
CX34−60D−6F Factory TXV
48,000 13.50 11.00 4270
3
CX34−49C−6F Factory TXV
48,500 13.50 11.00 4270
3
CX34−62D−6F Factory TXV
49,000 13.50 11.50 4270
3
CX34−62C−6F Factory TXV
Up-Flow Indoor Coils + Furnace Up−Flow Coils + Furnace
47,000 13.50 11.00 4155 CX34−50/60C−6F
4
G61MPV−60C−110 Factory TXV
47,000 13.50 11.00 4155 CX34−50/60C−6F
4
G71MPP−60C−110 Factory TXV
47,000 13.50 11.00 4165 CX34−50/60C−6F
4
G61MPV−60C−090 Factory TXV
47,000 13.50 11.00 4165 CX34−50/60C−6F
4
G71MPP−60C−090 Factory TXV
47,500 13.50 11.50 4115 CX34−50/60C−6F
4
G60UHV−60C−110 Factory TXV
47,500 13.50 11.50 4120 CX34−50/60C−6F
4
G60UHV−60C−090 Factory TXV
47,500 13.50 11.50 4145 CX34−43C−6F
4
G71MPP−60C−110
2
91M02
47,500 13.50 11.50 4145 CX34−43C−6F
4
G61MPV−60C−110
2
91M02
47,500 13.50 11.50 4155 CX34−43C−6F
4
G71MPP−60C−090
2
91M02
47,500 13.50 11.50 4155 CX34−43C−6F
4
G61MPV−60C−090
2
91M02
47,500 14.00 11.50 4105 CX34−43C−6F
4
G60UHV−60C−110
2
91M02
48,000 14.00 11.50 4110 CX34−43C−6F
4
G60UHV−60C−090
2
91M02
48,500 14.00 11.50 4080 CX34−60D−6F
4
G61MPV−60D−135 Factory TXV
48,500 14.00 11.50 4080 CX34−60D−6F
4
G71MPP−60D−135 Factory TXV
48,500 14.00 11.50 4110 CX34−49C−6F
4
G60UHV−60C−110 Factory TXV
48,500 14.00 11.50 4155 CX34−49C−6F
4
G61MPV−60C−110 Factory TXV
48,500 14.00 11.50 4155 CX34−49C−6F
4
G71MPP−60C−110 Factory TXV
48,500 14.00 11.50 4160 CX34−49C−6F
4
G61MPV−60C−090 Factory TXV
48,500 14.00 11.50 4160 CX34−49C−6F
4
G71MPP−60C−090 Factory TXV
48,500 14.00 12.00 4020 CX34−60D−6F
4
G60UHV−60D−135 Factory TXV
49,000 14.00 11.50 4120 CX34−49C−6F
4
G60UHV−60C−090 Factory TXV
49,000 14.00 11.50 4180 CX34−62C−6F
4
G61MPV−60C−090 Factory TXV
49,000 14.00 11.50 4180 CX34−62C−6F
4
G71MPP−60C−090 Factory TXV
49,000 14.00 12.00 4025 CX34−62D−6F
4
G60UHV−60D−135 Factory TXV
49,000 14.00 12.00 4085 CX34−62D−6F
4
G61MPV−60D−135 Factory TXV
49,000 14.00 12.00 4085 CX34−62D−6F
4
G71MPP−60D−135 Factory TXV
49,500 14.00 11.50 4135 CX34−62C−6F
4
G60UHV−60C−090 Factory TXV
49,500 14.00 11.50 4305 CX34−62C−6F
4
G61MPV−60C−110 Factory TXV
49,500 14.00 11.50 4305 CX34−62C−6F
4
G71MPP−60C−110 Factory TXV
49,500 14.00 12.00 4130 CX34−62C−6F
4
G60UHV−60C−110 Factory TXV
1
Certified in accordance with USE certification program which is based on ARI Standard 210/240; 95_F outdoor air temperature, 80_F db/67_F wb entering evaporator air
with 25 ft. of connecting refrigerant lines.
2
Factory installed RFC or expansion valve on indoor unit MUST be replaced with expansion valve kit (ordered separately) shown.
3
Blower must be capable of time−off blower delay. Indoor Blower Off Delay Relay (58M81) is recommended for field installation.
4
Blower control must be set for a time−off blower delay.
5
Most popular indoor coil.
