3 Preparation before Installation
NOTE:
Graphics here are only for reference. Please refer to actual products. Unspecified
dimensions are all in mm.
3.1 Standard Parts
Please use the supplied standard parts as required.
Parts for Outdoor Unit
No.
Name
Appearance
Qty
Remark
1 User Manual
1
2
Wiring (match with
resistance)
1
Must be connected to the
last IDU of communication
connection
3 Corrugated pipe
1
4 Chassis gluey plug
3
5 Drainage joint
1
6
Tube Connector
Sub-assay
1
VEP027N432US
VEP034N432US
VEP042N432US
NOTE:
Some accessories are not available for some models. Please refer to the present
product for details.
