Parts Arrangement - Non-Ducted Indoor Units
V22B or V33B Cassette
Cassette may be adjusted to provide discharge
air from one, two, three or four sides.
GROUNDING SCREW
(In control box)
RETURN AIR
AIR FILTER
DIFFUSER LOUVER
ADJUSTMENT LEVER
VCFB
Ceiling- or Floor-Mounted Non-Ducted Unit
RETURN AIR
DISCHARGE AIR LOUVER
AIR FILTER
VWMB
Wall-Mounted Non-Ducted Unit
RETURN AIR
GROUNDING SCREW
(In control box)
DISCHARGE AIR LOUVER
AIR FILTER
(Open front cover)
VOWA
One-Way Cassette
DISCHARGE AIR LOUVER
AIR FILTER
(Open return air grille)
RETUN AIR GRILLE
Slide to release
return air grille
Lift tab
to remove
filter
