XP19 SERIES
** Amount of charge required in additional to charge shown
on unit nameplate. Remember to consider line set length
difference.
Table 4  XP19−024
INDOOR HEAT
MATCH−UP PUMP
TargetSubcooling
HeatingCooling
(+
5ºF)(+1ºF)
**Add
charge
lb oz
C33−31 12 7 0 1
C33–38 SN# before SN#6007K 31 7 0 6
C33–38 SN#6007K and after 10 8 0 6
CBX27UH−030−230 10 6 0 6
CB30U−31 12 7 0 1
CB30U−41 10 6 0 6
CB31MV−41 10 6 0 6
CBX32M−030−230 12 7 0 1
CBX32M−036−230 10 6 0 6
CBX32MV−024/030−230 12 8 0 0
CBX32MV−036−230 10 6 0 6
CBX40UHV−024, −030 12 8 0 0
CBX40UHV−036 10 6 0 6
CH33−44/48, −48C 8 7 1 0
CR33−48 6 6 1 3
CR33−50/60 8 6 1 0
CR33−60 8 6 1 0
CX34−31 12 7 0 1
CX34−38 SN# before SN#6007K 31 7 0 6
CX34−38 SN#6007K and after 10 8 0 6
Table 5  XP19−036
INDOOR HEAT
MATCH−UP PUMP
TargetSubcooling
HeatingCooling
(+
5ºF)(+1ºF)
**Add
charge
lb oz
C33−38 SN# before SN#6007K 31 7 0 0
C33−38 SN#6007K and after 10 8 0 0
C33−44, −48 14 6 0 7
C33−49 6 6 1 5
C33−50/60C 12 5 0 13
C33−60D 8 5 0 15
C33−62D 6 6 1 5
CH23−51 14 6 0 5
CH23−65 12 5 0 13
CBX27UH−036−230 14 6 0 7
CBX27UH−042−230 6 6 1 5
CB29M−51 6 6 1 5
CB30M−41, −46 14 6 0 7
CB30M−51 6 6 1 5
CB30U−51 6 6 1 5
CB31MV−41 14 6 0 7
CB31MV−51 6 6 1 5
CBX32M−036−230 14 6 0 7
CBX32M−042−230 14 6 0 7
CBX32M−048−230 6 6 1 5
CBX32MV−036−230 14 6 0 5
CBX32MV−048−230 6 6 1 5
CBX40UHV−036 14 6 0 5
CBX40UHV−042, −048 6 6 1 5
CH33−44/48B 12 5 0 13
CH33−48 12 5 0 13
CR33−48 30 5 0 0
CR33−50/60, −60 15 4 1 5
Table 8  XP19−036 (Continued)
INDOOR HEAT
MATCH−UP PUMP
TargetSubcooling
HeatingCooling
(+
5ºF)(+1ºF)
**Add
charge
CX34−48 SN# before SN#6007K 31 7 0 0
CX34−48 SN#6007K and after 10 8 0 0
CX34−44/48 30 5 0 0
CX34−49 6 6 1 5
CX34−50/60C 12 5 0 13
CX34−60D 8 5 0 15
CX34−62D 6 6 1 5
Table 6  XP19−048
INDOOR HEAT
MATCH−UP PUMP
TargetSubcooling
HeatingCooling
(+
5ºF)(+1ºF)
**Add
charge
lb oz
C33−49 13 5 0 5
C33−60D 20 4 0 0
C33−62C, −62D 12 5 0 8
CBX27UH−048−230 13 5 0 5
CBX27UH−060−230 13 5 0 5
CB30M−51, −65 13 5 0 5
CB30U−51, −65 13 5 0 5
CB31MV−51, −65 13 5 0 5
CBX32M−048−230 13 5 0 5
CBX32M−060−230 13 5 0 5
CBX32MV−048−230 13 5 0 5
CBX32MV−060−230 13 6 0 5
CBX32MV−068−230 10 6 0 13
CBX40UHV−048 13 5 0 5
CBX40UHV−060 13 6 0 5
CH23−68 12 7 0 13
CH33−50/60C 20 7 0 5
CH33−62D 13 5 0 5
CR33−50/60. −60 20 4 0 5
CX34−49 13 5 0 5
CX34−60D 20 4 0 0
CX34−62C, −62D 12 5 0 8
Table 7  XP19−060
INDOOR HEAT
MATCH−UP PUMP
TargetSubcooling
HeatingCooling
(+
5ºF)(+1ºF)
**Add
charge
lb oz
C33−49 16 5 1 0
C33−60D 24 5 0 0
C33−62C, −62D 13 5 0 11
CBX27UH−060−230 16 5 1 0
CB30M−51, −65 16 5 1 0
CB30U−41, −65 16 5 1 0
CB31MV−51, −65 16 5 1 0
CBX32M−048−230 16 5 1 0
CBX32M−060−230 16 5 1 0
CBX32MV−048−230 16 5 1 0
CBX32MV−060−230 16 6 1 0
CBX32MV−068−230 14 4 1 0
CBX40UHV−048 16 5 1 0
CBX40UHV−060 16 6 1 0
CH23−68 14 4 1 0
CH33−62D 18 4 1 0
CR33−50/60, −60 24 5 0 0
CX34−49 16 5 1 0
CX34−60D 24 5 0 0
CX34−62C, −62D 13 5 0 11
