TABLE 3
ZCC/ZHC ELECTRIC HEAT SECTION FUSE RATING
EHA QUANTITY
& SIZE
VOLTAGES
FUSE (3 each)
F3 - 1 F3 - 2 F3 - 3 F3 - 4
EHO075-7.5
208/230V 25 Amp 250V ----- ----- -----
460V 15 Amp 600V ----- ----- -----
575V 10 Amp 600V ----- ----- -----
EHO150-1
208/230V 50 Amp 250V ----- ----- -----
460V 25 Amp 600V ----- ----- -----
575V 20 Amp 600V ----- ----- -----
EHO225-1
208/230V 50 Amp250V ----- ----- 25 Amp 250V
460V 25 Amp 600V ----- ----- 15 Amp 600V
575V 20 Amp 600V ----- ----- 10 Amp 600V
EHO300-1
208/230V 50 Amp 250V ----- ----- 50 Amp 250V
460V 25 Amp 600V ----- ----- 25 Amp 600V
575V 20 Amp 600V ----- ----- 20 Amp 600V
EHO450-1
208/230V 50 Amp 250V ----- 60 Amp 250V 60 Amp 250V
460V 25 Amp 600V ----- ----- 50 Amp 600V
575V 20 Amp 600V ----- ----- 40 Amp 600V
EHO600-1
208/230V 60 Amp 250V 60 Amp 250V 60 Amp 250V 60 Amp 250V
460V 50 Amp 600V ----- ----- 50 Amp 600V
575V 40 Amp 600V ----- ----- 40 Amp 600V
