g
Figure19.RemovetheDC-incable
Table8.Screwspecifications—removingtheLCDmodule
Screw
label
SpecificationsColor
Torque
5
M2×3mm,flat-head,nylon-coated
Black
1.85+/-0.15kgf-cm
RefertoTable3“PartnumbersforFRUs(CRUs)”onpage22tolookuptheLenovopartnumbersofthe
followingreplacementparts:
Systemboard
DC-incable
Basecover
Removethetouchpadmodule
“Removetheuppercaseandthebattery”onpage25
Step1.Openthesocket1,pulloutthetouchpadcable2,andthenpeeloffthetouchpadcablefrom
theuppercase.
b
a
Figure20.Removethetouchpadmodule
Step2.Removethethreescrews4,andthenremovethetouchpadholderinthedirectionshownby
arrow5.
Chapter4.RemovingaFRUorCRU33
