Step 3. Remove three screws and remove the fan.
Screw specifications Number of screws
M2 x 3.5 2
M2 x 5 1
Figure 17. Remove three screws and remove the fan
Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
Fan
Remove the solid-state drive
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 28
Chapter 4. Removing a FRU or CRU 37

Lenovo 15IIL05 Specifications

General

Operating System	Windows 10 Home
Processor	Intel Core i3-1005G1 / i5-1035G1 / i7-1065G7
Storage	Up to 512GB SSD
Display	15.6" FHD (1920x1080) IPS
Graphics	Intel UHD Graphics
Battery	35Wh
RAM	12GB DDR4
