Lenovo 300e User Manual

Chapter 5. Removing a FRU or CRU
General guidelines
When removing or replacing a FRU, ensure that you observe the following general guidelines:
1. Do not try to service any computer unless you have been trained and certified. An untrained person runs
the risk of damaging parts.
2. Begin by removing any FRUs that have to be removed before replacing the failing FRU. Any such FRUs
are listed at the beginning of each FRU replacement procedure. Remove them in the order in which they
are listed.
3. Follow the correct sequence in the steps for removing a FRU, as shown in the illustrations by the
numbers in square callouts.
4. When removing a FRU, move it in the direction as shown by the arrow in the illustration.
5. To install a new FRU in place, perform the removal procedure in reverse and follow any notes that
pertain to replacement.
6. When replacing a FRU, carefully retain and reuse all screws. If screws are missing, look up the Lenovo
parts numbers by visiting
https://support.lenovo.com/partslookup for replacement screws and order them
through the Lenovo CRM system.
7. When replacing the base cover, reapply all labels that come with the replacement base cover. If some
original labels are not included with the replacement base cover, peal them off from the original base
cover and paste them on the replacement base cover.
DANGER
Before removing any FRU or CRU, shut down the computer and unplug all power cords from
electrical outlets.
Attention: After replacing a FRU, do not turn on the computer until you have ensured that all screws,
springs, and other small parts are in place and none are loose inside the computer. Verify this by shaking the
computer gently and listening for rattling sounds. Metallic parts or metal flakes can cause electrical short
circuits.
Attention: The system board is sensitive to and can be damaged by ESD. Before touching it, establish
personal grounding by touching a ground point with one hand or by using an ESD strap (P/N 6405959).
Remove Lenovo Integrated Pen
Make sure the computer has been shut down before servicing the computer.
Step 1. Place the computer upside down on a flat surface.
Step 2. Pull out Lenovo Integrated Pen from the pen slot.
© Copyright Lenovo 2020 35

Lenovo 300e Specifications

General

Tjunction	105 °C
Processor cache	4 MB
Processor cores	4
Processor model	N4120
System bus rate	- GT/s
Processor family	Intel® Celeron® N
Processor socket	BGA 1090
Processor codename	Gemini Lake Refresh
Processor frequency	1.1 GHz
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor boost frequency	2.6 GHz
Processor operating modes	64-bit
PCI Express configurations	1x4+1x2, 4x1, 2x1+1x2+1x2
Thermal Design Power (TDP)	6 W
Maximum number of PCI Express lanes	6
Discrete graphics card	No
On-board graphics card	Yes
Number of execution units	12
On-board graphics card ID	0x3185
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics 600
On-board graphics card family	Intel® UHD Graphics
Maximum on-board graphics card memory	8 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	200 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	700 MHz
Form factor	Convertible (Folder)
Product type	Hybrid (2-in-1)
Product color	Black
Housing material	Acrylonitrile butadiene styrene (ABS)
Display diagonal	11.6 \
Display brightness	250 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Internal memory	4 GB
Memory clock speed	2400 MHz
Memory form factor	On-board
Internal memory type	LPDDR4-SDRAM
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	NVMe, PCI Express
Storage media	SSD
SSD form factor	M.2
Total storage capacity	128 GB
Compatible memory cards	MicroSD (TransFlash)
Number of SSDs installed	1
Battery capacity	42 Wh
Battery life (max)	10 h
AC adapter power	45 W
Audio chip	Realtek ALC3287
Speaker power	2 W
Number of built-in speakers	2
Password protection type	Power on, Supervisor
WWAN	Not installed
Antenna type	2x2
Bluetooth version	5.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN controller model	Intel Dual Band Wireless-AC 9560
Sustainability certificates	RoHS, EPEAT Silver
Certification	MIL-STD-810G
USB 2.0 ports quantity	0
Keyboard layout	QWERTY
Pointing device	Touchpad
Keyboard language	English
Processor ARK ID	197309
Processor package size	25 x 24 mm
Supported instruction sets	SSE4.2

Weight and Dimensions

Depth	204 mm
Width	290 mm
Height	20.85 mm
Weight	1310 g
