Lenovo 500e Chromebook Gen 3 User Manual

Chapter 3. Create and use a USB repair shim
This chapter contains the following topics:
“What is a USB repair shim?” on page 25
“Create a USB repair shim” on page 25
“Use the USB repair shim” on page 26
What is a USB repair shim?
You can create a USB repair shim by writing a repair shim image to a USB storage drive. With the USB repair
shim, you can:
• Refresh the Chromebook system with the latest firmware.
• Diagnose problems and restore the system to factory settings.
Note: Before replacing any FRUs, use the USB repair shim to diagnose and identify problems.
When you use the USB repair shim to diagnose problems, the Chromebook enters the factory-test-image
environment and runs through the following factory test items.
Table 1. Factory test items
Test item Description
Final Functional Test (FFT)
The FFT is designed to test the function of individual component, such as the display,
audio, camera, and keyboard.
Some test items might require an HDMI
™
monitor or SD card. If the devices are not
available, the tests can be bypassed. As a result, the overall test is marked as failed.
RunIn and FAT
The RunIn and FAT are designed to test how the system functions under stress by
running the maximum workload. It takes about 10 minutes to finish.
Google Required Tests
(GRT)
The GRT is designed to check the system status and help reset the system back to
factory settings. If any test fails, the GRT has to be forced to end.
Create a USB repair shim
Step 1. Prepare a USB storage drive with at least 8 GB of storage capacity.
Attention: The creation process deletes anything stored on the USB storage drive. To avoid data
loss, backup all the data that you want to keep.
Step 2. Download the image file of the repair shim from
https://support.lenovo.com. A Lenovo service
credential is required to download the image file.
Note: Make sure to download the latest version of the image file. A shim created with an earlier
version of the image file might cause the repair process to fail.
Step 3. Use a disk imaging tool to write the downloaded image to the USB storage drive. An open-source
tool Win32 Disk Imager is available at
http://sourceforge.net/projects/win32diskimager.
© Copyright Lenovo 2022 25

Lenovo 500e Chromebook Gen 3 Specifications

General

Form factor	Convertible (Folder)
Product type	Chromebook
Product color	Gray
Housing material	Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC)
Built-in stylus pen storage	Yes
Color gamut	50 %
Display surface	Gloss
RGB color space	NTSC
Display diagonal	11.6 \
Display brightness	250 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Processor cache	4 MB
Processor cores	4
Processor model	N5100
Processor family	Intel® Celeron® N
Processor frequency	1.1 GHz
Processor cache type	L3
Processor manufacturer	Intel
Processor boost frequency	2.8 GHz
Motherboard chipset	Intel SoC
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	2933 MHz
Memory form factor	On-board
Internal memory type	LPDDR4x-SDRAM
Storage media	eMMC
Optical drive type	No
Total storage capacity	64 GB
Compatible memory cards	MicroSD (TransFlash)
Discrete graphics card model	Not available
On-board graphics card family	Intel® UHD Graphics
Audio chip	Realtek ALC5682I-CGT
Speaker power	2 W
Number of built-in speakers	2
Privacy type	Privacy shutter
Front camera resolution (numeric)	5 MP
WWAN	Not installed
Antenna type	2x2
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX201
HDMI version	1.4b
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Keyboard layout	QWERTY
Pointing device	Touchpad
Keyboard language	Portuguese
Operating system installed	ChromeOS
Battery capacity	42 Wh
AC adapter power	65 W
Cable lock slot type	Kensington
Sustainability certificates	ENERGY STAR, EPEAT Silver, ErP, RoHS, TCO

Weight and Dimensions

Depth	202.4 mm
Width	289.6 mm
Height	19.9 mm
Weight	1330 g
