Lenovo B460e User Manual

34
Appendix. CRU instructions
To make sure that the DDR3 SDRAM is installed correctly, do as follows:
1 Turn the computer on.
2 Hold F2 during startup. The BIOS setup utility screen opens. The System Memory item
shows the total amount of memory installed in your computer.
Note: If only one DDR3 SDRAM is used on the computer you are servicing, the card must be installed in
SLOT-0 ( : lower slot), but not in SLOT-1 ( : upper slot).

Lenovo B460e Specifications

General

Graphics	Intel HD Graphics
Storage	Up to 500 GB HDD
Wireless	802.11 b/g/n
Webcam	0.3MP
Battery	6-cell Li-Ion
CPU	Intel Celeron
Chipset	Intel HM55
Memory	Up to 4GB DDR3
Display	14.0" HD (1366x768)
Optical Drive	DVD
LAN	10/100 Mbps
Ports	USB 2.0, VGA, HDMI, RJ-45
Card Reader	SD, MMC
Operating System	Windows 7
Weight	2.2kg
